accessories pressure switch type HED 2 pressure switch type HED 3 pressure switch type USPH 1 pressure switch type USPH 4 pressure gauge isolator valve type UOPF 1 multi-circuit gauge isolator type UOPF 4 multi-circuit gauge isolator valve type UOPF 6 2-way ball type valve BK 3-way ball type valve 3BK 4-way ball type valve 4BK oil filter/air breather type UOFP hydraulic hand pump two-stage type UPTR 12/1,6 foot-operated pump typ UPTN5-02.SO454 oil level indicator type UOSP oil pumping and filtering unit type UYFA 15

-1- WK 450 239 WK 450 239 up to 40 MPa 04.2001r. PRESSURE SWITCH TYPE HED 2 DESCRIPTION OF OPERATION Pressure switch type HED 2 is used to switch an electrical circuit on and off in relation to the given pressure value of an oil or another operating medium. Increasing pressure is supplied by a dumping tube via connector Stecko 4 sealed with the rubber ring 8. This pressure affects the bourdon tube 2 causing its deformation. As soon as the set pressure is reached, the bourdon tube actuates the micro switch 3 by means of the attached operating lever. Position of the micro switch and than time...

WK 450 239 - 2 - TECHNICAL DATA Note : Fixing bolts have to be ordered separately. Setting ranges [ MPa ] Decreasing pressure Increasing pressure min max min max 0.15 0.4 0.6 1 2 2.5 6.3 10 20 40 0.2 0.5 0.75 1.4 2.6 2.6 6.4 10.15 20.4 40.6 Fixed switching pressure difference [ MPa ] Pressure rating [ MPa ] Maximum operating pressure [ MPa] ~ 0.05 ~ 0.10 ~ 0.15 ~ 0.40 ~ 0.60 2.5 6.3 10 20 40 3 7 11 21 42 Operatin medium Mineral oil, phosphate ester, gas, air Electrical connection with a gland PG 11 ; max conductor dia = 8 Insulation Electrical connection with a gland IP 55 IP 54 Mounting...

-3- WK 450 239 OVERALL AND CONNECTION DIMENSIONS Overall dimensions and connector Item 1 - o-ring 5.3 × 2.4 - 1 piece Item 2 - Dumping tube ( not included )

WK 450 239 - 4 - ”Z” Electrical connection SCHEMES Graphical symbol Symbol of electrical connections for version Z4L brown yellow black green and yellow

-5- WK 450 239 HOW TO ORDER Orders coded in the way showed below should be forwarded to the manufacturer. Series number 31 = 31 ( 30 - 39 ) - installation and connection dimensions remain unchanged Further requirements in clear text ( to be agreed upon with the manufacturer ) Maximum set pressure 2.5 MPa = 25 6.3 MPa = 63 10 MPa = 100 20 MPa = 200 40 MPa = 400 Voltage of control light 24 V = 24 110 V = 110 220 V = 220 Electrical connection Standard version = no designation Angled plug = Z Angled plug with light = ZL Central connector = K Central connector with light = KL Control light = L...

-1- WK 450 240 WK 450 240 up to 40 MPa 04. 2001r. PRESSURE SWITCH TYPE HED 3 Pressure switch type HED 3 is used to switch an electrical circuit on and off in relation to the given pressure value of an oil or another operating medium. DESCRIPTION OF OPERATION Increasing pressure is supplied by a dumping tube via connector Stecko 4 sealed with the rubber ring 8. This pressure affects the bourdon tube 2 causing its deformation. As soon as the set pressure is reached, the bourdon tube actuates the micro switch 3 by means of the attached operating lever. The pressure switch is equipped with two...

WK 450 240 - 2 - TECHNICAL DATA Note : Fixing bolts have to be ordered separately. Setting ranges [ MPa ] Decreasing pressure Increasing pressure min max min max 0.15 0.4 0.6 1.0 2.0 2.5 6.3 10 20 40 0.25 0.6 0.9 1.8 3.2 2.6 6.5 10.3 20.8 41.2 Fixed switching pressure difference [ MPa ] Pressure rating [ MPa ] Maximum operating pressure [ MPa] 0.1 - 2.35 0.2 - 5.9 0.3 - 9.4 0.8 - 19 1.2 - 38 2.5 6.3 10 20 40 3 7 11 21 42 Operatin medium Mineral oil, phosphate ester, gas, air Electrical connection with a gland PG 11 ; max conductor dia = 8 Insulation Electrical connection with a gland IP 55...

-3- WK 450 240 Overall dimensions and connector Item 1 - o-ring 5.3 × 2.4 - 1 piece Item 2 - Dumping tube ( not included ) OVERALL AND CONNECTION DIMENSIONS

WK 450 240 - 4 - ”Z” SCHEMES Electrical connection Graphical symbol Symbol of electrical connections for version Z4L brown yellow black green and yellow

-5- WK 450 240 Series number 40 = 40 ( 40 - 49 ) - installation and connection dimensions remain unchanged Maximum set pressure 2.5 MPa = 25 6.3 MPa = 63 10 MPa = 100 20 MPa = 200 40 MPa = 400 Coding example : HED 30 A 40/100ZL 110 HED 3 0 A * Further requirements in clear text ( to be agreed upon with the manufacturer ) Voltage of control light 24 V = 24 110 V = 110 220 V = 220 Electrical connection Standard version = no designation Angled plug = Z Angled plug with light = ZL Central connector = K Central connector with light = KL Control light = L Plug with light = Z4L Lockable cap...

-1- WK 450 175 WK 450 175 up to 35 MPa 04.1999r. PRESSURE SWITCH TYPE USPH 1 Pressure switch type USPH 1 serves to switch an electrical circuit on and off by means of a micro switch under the influence of pressure variations in relation to the set pressure. The pressure switch may be used to control or monitor processes i.e. by means of a visual ( light ) or acoustic ( bell ) indicator. DESCRIPTION OF OPERATION At initial state the piston 2 is held in its lower position by the spring 4 and causes the lever 5 to press the micro switch end 6. Pressure affects the piston which pushes against...

WK 450 175 - 2 - TECHNICAL DATA OVERALL DIMENSIONS a) setting element with adjusting screw ,,2'' b) setting element with lackable handknob ,,3'' c) setting element with hand knob ,,1'' 1 - o-ring 10 × 2 - 1 piece 2 - o-ring 7 × 1.5 - 1 piece Hydraulic fluid Mineral oil or phosphate ester Nominal fluid viscosity 37 mm2/s at the temperature of 328 K Viscosity range Optimum working temperature Fluid temperature range ( fluid in a tank ) 313 - 328 K Filtration Maximum operating pressure 35 MPa up to 16 ìm 243 - 343 K 2.8 to 380 mm2/s Switching repeatibility ± 2.5 % of pressure setting Maximum...
