i
the pdlylube bearing part number System
pgp16f18-16
(1.00" ID x 1.125" CD x 1.00 Long) "Liner F= Fiber Series T= Tape Series
I B
FblyLube
Inside
Teflon*
Outside
Length
Identification
Dameter in
Liner
Diameter in Yie"
PGP
XX
F
XX
XX
polygon pww inch séries
Al measurements in inches.
thrust bearings
ï dimens
ions
bearing part number
nominal id
id
od
thickness
PWW04F08-3
1/4
0.2e40
0.4800
0.0e80
0.2540
0.5000
0.0880
PWW06F12-3
3/8
0.3890
0.7300
0.0e80
0.3790
0.7500
0.0880
PWW08F16-3
1/2
0.5130
0.9800
0.0e80
0.5030
1.0000
0.0880
PWW10F20-3
5/8
0.e380
1.2480
0.0e80
0.e280
1.2500
0.0880
PWW12F24-3
3/4
0.7e40
1.4800
0.0e80
0.7540
1.5000
0.0880
PWW14F28-3
7/8
0.8880
1.7300
0.0e80
0.8780
1.7500
0.0880
PWW16F32-3
1
1.0140
1.9800
0.0e80
1.0040
2.0000
0.0880
PWW18F34-3
1-1/8
1.1500
2.1050
0.0e80
1.1300
2.1250
0.0880
PWW20F3e-3
1-1/4
1.2730
2.2300
0.0680
1.2530
2.2500
0.0880
PWW22F40-3
1-3 /8
1.3990
2.4800
0.0e80
1.3790
2.5000
0.0880
PWW24F42-3
1-1/2
1.5240
2.e050
0.0680
1.5040
2.e250
0.0880
PWW2eF44-3
1-5/8
1.e490
2.7300
0.0680
1.e290
2.7500
0.0880
PWW28F4e-3
1-3 /4
1.7740
2.8550
0.0680
1.7540
2.8750
0.0880
PWW32F52-3
2
2.0240
3.2300
0.0680
2.0040
3.2500
0.0880
PWW3eF54-3
2-1 /4
2.2730
3.3550
0.0680
2.2530
3.3750
0.0880
PWW40Fe0-3
2-1 /2
2.5240
3.7300
0.0680
2.5040
3.7500
0.0880
PWW44F66-3
2-3/4
2.7740
4.1050
0.0680
2.7540
4.1250
0.0880
PWW48F72-3
3
3.0240
4.4800
0.0680
3.0040
4.5000
0.0880
46 ★
The high strength fiberglass laminate allows for high compressive loading and excellent resistance to impact.
