FAPOS 2/2 • 150 V

• three dimensional systemfor fiber positioning• compact size, easy to use • mechanical motion in x, yand z direction, 5 mm• optional 3D piezoelectricmotion for the highest requirements

side B is completed with an element for mecha- nical fiber rotation (combination of part no. O-105-06, O-205-00). Side A can be adjusted using microme-ter drives for mechanical motion in x-, y- and z-direction. Side B can be equippedwith a TRITOR element for finest piezoelectric motion up to 100 µm. Several accessories such as fiber holders or holders for microobjectives are avail- able and can be mounted on the top plate on both sides. In the picture FAPOS 2/2 was developed especially forprecision positioning of optical compo- nents, e.g. fiber coupling problems. Compact size and a modular design allow flexible and universal applications.

technical data:

micrometer drive: motion (x, y, z):5 mm (ball bearing guide) scale division:0.01 mm positioning accuracy:< 1 µm guide accuracy:< 1 µm options side A: differential micrometer drive 5 mm positioning accuracy:< 0.5 µm options side B: • 3D piezostage motion (x, y, z) 40 µm with nanometer resolution• 3D piezostage motion (x, y, z) 100 µm with nanometer resolution• integrated strain gauge measurement system • elements for mechanical fiber rotation:– part no. O-201-00: V-notch fiber holder – part no. O-202-00: objective mount for microscopeobjectives– part no. O-205-00: mechanical fiber rotator – part no. O-206-00: piezoelectrical fiber rotator

configurations:

namepart no.side Aside B 3D mech. motion3D mech. motion3D motion piezo-with strain gauge micrometer drivediff. microm. driveelectrical systemmeasurement systemFAPOS 2/2O-104-005 mm--––FAPOS 2/2 DMO-104-20–5 mm--– FAPOS 2/2 P40O-105-045 mm–40 µm– FAPOS 2/2 P100O-105-065 mm–100 µm– FAPOS 2/2 P40 SGO-106-045 mm–40/32 µm*x FAPOS 2/2 P100 SGO-106-055 mm–100/80 µm*x* open loop / closed loop

36 FAPOS 2/2 micro objectiv holderV-notch fiber holder
