piezogripper grippy IIIfibergripper
• 275 µm gap motion • variable gap shape design
• adjustable grip force
• high speedapplication: S-805-00
O-400-00
• micro optics manipulation• fiber optics assembly
• precision mounting and adjusting
• biological sample manipulationThe piezogripper was designed formicro systems handling applications.
The accurate and high speed motion of
a piezoactuator is transformed by the
levered transmission of a solid state
hinge joint to a 300 µm opening of the
gripper gap.
Because of its compact dimensions, the piezogripper is well suited for OEM
applications.
All kinds of handling and manipulating
of small parts in research labs or indu-
stry are potential applications for the
piezogripper.
54.5 49 M2
3818 technical data:
part no.S-805-00O-400-00 free gap:300 µmfree gripper motion:275 µm300 µm
operating voltage:–10 to 150 V–10 to 150 V
capacitance:0.8 µF1.7 µF
temperature range:–20 to 80 °C–20 to 80 °C
dimensions (in mm):54.5 x 38 x 758 x 12 x 14.5
4
4
5 7 7
options:
gripper gap shape per customer request
moving part detaildetail (scale of 5:1)
-V-grove ° 6.5 1.5
0.2 (90 M3x4 (2x)
51 58 28 18 10 2.5
4 12 14.5 ± 0.5
