tilting systems

series PSH 35 • 150 V

• 35 mrad (2°) tilting angle• high dynamics due tohigh resonant frequency• compact size • easy to controlapplications

piezosystem jena .Please note: Piezoelements can requiresome current for charging and dis- charging processes during dynamic motions. The element is normally delivered with- out a mirror. A mirror can be attached by gluing. We recommend an operating voltage not higher than 100 V for permanent work under OEM conditions. • scanners• laser alignment • beam deflection • handling systemsThe PSH 35 tilting system was devel-oped for the dynamic motion of small mirrors. A new construction principle makes it possible to reach a tilting angle of 35 mrad. The element is operated by a maximum voltage of 150 V. It can be easily integrated into more complex stages because of its compact size. The PSH 35 tilting element can be driven by any of the power supplies from

PSH 35

mirror (not included) pivot
27 25 202 18 54 4xø2.2/ø4x10 B 4.75 (8.0 for SG version)mounting area ø 7.0 60
9.5 85 20 sensor cable (PSH 35 SG only) ø7

PSH 35 SG

series PSHPSH 35 part no.K-232-00tilting angle (±10%)**in mrad35 (2°)operating voltagein V–10 to +150 capacitance (±20%)***in µF3.8 weightin g50 resonant frequencyin kHz1.9 resolution open loop*in µrad0.04 temperature range–20 to 80 °C dimensionslength Lin mm60width Bin mm14 height Hin mm27connectorLEMOSA cable length1 m series PSHPSH 35 SG part no.K-232-01dimensionslength Lin mm60width Bin mm20 height Hin mm27connectorLEMOSA cable length1 m*measured with E-103-18 amplifier**typical value measured with –10V to 150V ***typical value for small electrical field strength

piezosystem jena

31
