tilting systems

series PSH • 150 V

Mirror mounts are pre-loaded. They can work under pulling and pushing forces. Because of their construction they are very sensitive to lateral forces between the housing and the top plate. During mounting we recommend the use of our mounting clamp. This part protects the housing and top plate while the mirror is installed.

example

part no. K-202-10:mirror mount with 2 mrad tilting and 18 µm z-motion with small tilting plate (type A).

chart of tilting systems explanation of tilting axes (see red lines in the drawing)

namepart. tilting Top plate Atop plate Bz-motionVacuumSGno.angle (small(largein µm optionoption
2 2 The red lines show the tilting axes if the x-, y- and z-axis are in operation. The increase of the tilting angle can be realized as follows: • Operation of the x-axis (tilting in one direction).• Equal operation of y- and z-axis(results in tilt in opposite direction). (mrad)25x25 mm )38x38 mm ) system PSH 1z AK-201-101x8xPSH 1z BK-201-201x8x PSH 1 AK-201-301x–x PSH 1 BK-201-401x–x PSH 1z A-SGK-201-111/0.8*x8xx PSH 1z B-SGK-201-211/0.8*x8xx PSH 1 A-SGK-201-311/0.8*x–xx PSH 1 B-SGK-201-411/0.8*x–xx PSH 2z AK-202-102x18x PSH 2z BK-202-202x18x PSH 2 AK-202-302x–x PSH 2 BK-202-402x–x PSH 2z A-SGK-202-112/1.6*x18xx PSH 2z B-SGK-202-212/1.6*x18xx PSH 2 A-SGK-202-312/1.6*x–xx PSH 2 B-SGK-202-412/1.6*x–xx PSH 3z AK-203-103x26x PSH 3z BK-203-203x26x PSH 3 AK-203-303x–x PSH 3 BK-203-403x–x PSH 3z A-SGK-203-113/2.4*x26xx PSH 3z B-SGK-203-213/2.4*x26xx PSH 3 A-SGK-203-313/2.4*x–xx PSH 3 B-SGK-203-413/2.4*x–xx PSH 4z AK-204-104x33x PSH 4z BK-204-204x33x PSH 4 AK-204-304x–x PSH 4 BK-204-404x–x PSH 4z A-SGK-204-114/3.2*x33xx PSH 4z B-SGK-204-214/3.2*x33xx PSH 4 A-SGK-204-314/3.2*x–xx PSH 4 B-SGK-204-414/3.2*x–xx PSH 8K-108-008ø14 mm45x PSH 8 SGK-108-018/6.4*ø14 mm45xx PSH 5/2K-105-00±2.5–x PSH 5/2 SGK-105-01±2.5/±2*–xx PSH 10/2K-110-00±5–x PSH 10/2 SGK-110-01±5/±4*–xx PSH 0.3/1 SGK-200-030.3+0.08xxx PSH 2/1 LVDTK-202-052x PSH 35K-232-0035–x PSH 35 SGK-232-0135/28*–xx* open loop/closed loopother configurations available on request

30 mounting instructions
