compact multi dimensional translation stages

series TRITOR • 150 V

• highly compact designresults in superior performance• accurate parallel motionby parallelogram design• high reliability due tosolid state hinges• motion without mechanical play• high resolution in nm andsub-nm range• motion up to 100 µm • precision pin holes • TRITOR 101 and 102 with free central hole (30 mm/40 mm)applications options

· optics, laser technique, fiber positioning· micromanipulation, biology · scanning systems · vacuum and low temperature applications • integrated measurement system foreach axis • vacuum design other modifications available onrequest piezosystem jena’s unique TRITOR elements are extremely compact but offer motions of up to 100 µm in all three axes. Parallel motion is achieved without play due to the mechanical design. As an option, an integrated strain gauge and capacitive measurement system for overcoming the effect of hysteresis is available. TRITOR elements can be easily combined with other mechanical positioning systems. They are suitable for many various applica- tions ranging from optical research to OEM systems. Probe alignment in microscopes manufacturer usuallyrequires an open center space (e.g. for the passage of light). The models TRITOR 101 and 102 with their 30 and 40 mm free central holes were develop- ed considering such applications. Each axis is mechanically pre-loaded, making the TRITOR 101 and 102 system very well suited for dynamic applications.The element with its solid state hingesis made of stainless steel except for the bottom and top plate, which are made of black-anodized aluminum. The TRITOR 101 and 102 translation systems can be driven by any amplifier from

mounting instructions

TRITOR elements consist of actuatorsintegrated in a housing with an inter- nal lever transmission. Since the lever mechanism works in both directions, forces between housing and top plate need to be avoided, as they could damage the stage. The stage is fixed by using two diagonal holes. Components can be mounted on the topped plate by two diagonal tap holes and can be accura-tely located by using the precision pin holes (indicated N).

technical data

operating voltage:–10 to +150 Vtemperature range:–20 to 80 °C housing:stainless steel; top and bottomplate made of anodized Alconnector:LEMOSA cable length:1 mrecommended supply:NV 40/3s; ENV 40; ENV 150; NV C1

26 TRITOR 101 TRITOR 102 TRITOR 101 CAP
