series TRITOR • 150 V

• highly compact designresults in superior performance• accurate parallel motionby parallelogram design• high reliability due tosolid state hinges• motion without mechanical play• high resolution in nm andsub-nm range• motion up to 100 µm • precision pin holesapplications options technical data
· optics, laser technique, fiber positioning· micromanipulation, biology · scanning systems · vacuum and low temperature applications • integrated measurement system foreach axis • vacuum design other modifications available on request operating voltage:–10 to +150 Vtemperature range:–20 to 80 °C housing:stainless steel; top and bottomplate made of anodized Alconnector:LEMOSA cable length:1 mrecommended supply:NV 40/3s; ENV 40; ENV 150; NV C1 piezosystem jena’s unique TRITOR elements are extremely compact but offer motions of up to 100 µm in all three axes. Parallel motion is achieved without play due to the mechanical design. As an option, an integrated strain gauge measurement system for overcoming the effect of hysteresis is available. TRITOR elements can be easily combined with other mechanical positioning systems. They are suitable for many various applications ranging from optical research to OEM systems. mounting instructions
TRITOR elements consist of actuators integrated in a housing with an inter- nal lever transmission. Since the lever mechanism works in both directions, forces between housing and top plate need to be avoided, as they could damage the stage. The stage is fixed by using two diagonal holes. Components can be mounted on the top plate by two diagonal tapped holes and can be accu- rately located by using the precision pin holes (indicated N). For fixing the MINITRITOR, please see the drawing.

piezosystem jena

23 TRITOR 100TRITOR 38 PX 100 CAP
