piezosystem jena positioning inthe nm and sub nm range about the full motion is possible. Because of the built-in lever transmission, the elements of the series PX 200 to PX 400 are very compact. They can be easily combined with other mechanical or electromecha- nical translation systems. The PX 400 HL translation system is the high-load version of the system PX 400. A vacuum option and integrated measurement systems are available.Using strain gauges (SG) as a measure-ment system, an accuracy of 0.2% of the maximum motion can be achieved.

compact one dimensional translation stages

series PX 200–PX 400 • 150 V

The construction of these elements is based on solid state flexure hinges in a parallelogram design. As a result, highest parallelism, no mechanical wear, and a high resolution over the full motion are characteristics for these translation systems. In combination with power supplies from • large motions with highest parallelism• motion up to 400 µm • solid state flexure hinges • 150 V multi-layer technology • vacuum option • option with integratedmeasurement system

compact one dimensional translation stages

series PX 500–PX 1500 • 150 V

• compact elements forlarge motions• motion up to 1500 applications:
• scanning systems• precision engineering • automation • optics, fiber optics • micro manipulationThe element PX 500 was developedespecially for OEM applications. Without external loads, the element reaches a motion of 590 µm. The construction is based on solid state hinges providing a levered transmission of the piezoelements. Thus, the element has very compact dimensions. The element can be mounted to a fixture using one of the holes (diameter 2.2 mm). The other hole will move in relation to this one.Due to the development of new levertransmission principles, the element PX 1500 is able to produce a maximum displacement of 1.5 mm. Because of its compact dimensions. The PX 500 and PX 1500 are very suitable for OEM applications. The lever transmission principle is based on solid state hinges with integrated pre-load. Therefore, high dynamic movement without mechanical play is possible. µm • high resonant frequency • integrated pre-load • motion without anymechanical playPX 500 PX 1500

piezosystem jena

11 PX 400
