accessoires

adapter and extensions cables

Piezosystem jena delivers all translation systems and positioning stages with 1 m (39.37 inches) cables and LEMO connectors FFA S-250-32. All systems for vacuum application are delivered with 1.2 m (47.25 inches) cables made of copper without connectors. Insulation material is Polymid.

extension cables


Types	length		type plug	type socket	part no.
	m	inches
LEMO (plug) -	1	40	FFA.0S.250	PCA.0S.250.32	Z-002-01
LEMO (socket)	3	118			Z-002-03
	6	235			Z-002-06
BNC (plug) -	1	40	BNC	BNC	Z-003-11
BNC (plug)	3	118			Z-003-13
	6	235			Z-003-16
LEMO (plug) -	1	40	FFA.1S.306	PCA.1S.306	Z-002-21
LEMO (socket)	3	118			Z-002-23
for strain gauge 7					Z-002-27

Z-002-0X** Z-003-1X** Z-002-2X**

sensors*

further cable extension per meter/inch

Z-101-00E

* additional cable length has influence on the calibration of the

measurement system ** last number x: cable length in m

adapter


Types	length	part no.
	m inches
LEMO (plug) - BNC (plug)	1 40	Z-001-23
LEMO (plug) - BNC (socket)	1 40	Z-001-24
LEMO (plug) - SMB (socket)	1 40	Z-001-26
LEMO (plug) -free*	1 40	Z-001-20
BNC (plug) -SMB (plug)	1 40	Z-001-36
BNC (plug) -free**	1 40	Z-001-30
BNC (plug) -SMB (socket)	connector	Z-001-39
BNC (plug) - BNC (socket)	angle connector Z-001-38
2 BNC (plug) - BNC (socket)	T-connector	Z-001-37
** cable side without connector
*connectors*
Types type connector		part no.
LEMO (plug) FFA.0S.250-32¹⁾		Z-006-10
LEMO (socket) PCA.0S.250-32²⁾		Z-006-11
LEMO (plug) FFA.1S.306-42		Z-006-30
LEMO (socket) PCA.1S.306-42		Z-006-31
BNC (plug)³⁾		Z-006-50
BNC (socket)³⁾		Z-006-51
SMB (plug)³⁾		Z-006-70
¹⁾ maximal cable diameter 3.2 mm
²⁾ maximal cable diameter 4.2 mm
³⁾ RG 174/179 for cable diameter up to 3.2 mm/0.125 inch



Z-001-23	Z-001-26	Z-001-36

Z-001-37 Z-001-38 Z-001-39

i v> ^ *

Z-006-10 Z-006-11 Z-006-30 Z-006-31

Z-006-50 Z-006-51 Z-006-70
