LUXEON® S LUXEON S Optimized solution for applications requiring high flux and tight beam control Technical Datasheet DS80 Introduction The LUXEON® S emitters deliver uniform beam intensity and high flux density from a uniform source. This enables tight beam control at the system level using secondary optics to provide the high center beam intensity, uniform beam and crisp, single shadow required for high performance accent spotlighting applications. LUXEON S delivers tight Correlated Color Temperature control to ensure consistency in system color point. In addition these parts deliver the efficacy, lifetime and reliability that all LUXEON LEDs are renowned for. This document contains the performance data needed to design and engineer LUXEON S based applications. LUXEON S features • Specified, targeted and tested hot, at real world operating temperatures: Tj = 85°C, to ensure in application performance • High flux density with 1300 lumens from an 8mm diameter source • Uniform intensity and color across source • Freedom from Binning delivers color consistency within a single 3-step MacAdam ellipse • Exceed ENERGY STAR® lumen maintenance requirements • High efficacy for sustainable design. High Flux Density
