The DMP200 series of universal input indicators offer unparalleled price andperformance and are ideal for industrial test and process applications. Surface mountand microprocessor technology has enabled powerful features to be packed into a 1/8 DIN case. The measurement performance is significantly better than that normallyassociated with indicators in this price range. Applications range from simplemeasurement only to more demanding situations requiring digital communications,alarms, maths functions and complex signal conditioning. The powerful menu-drivensoftware enables fast flexible...

Open the catalog to page 2

?Fast-Calђ calibration?Adjustable display resolution?Maximum / minimum memory?Isolated analogue output?Two logic inputs?Front panel function buttons?Transducer excitation supply?High speed analogue output?Universal mains power supply?Serial communications?Dual alarm relays?Quad TTL alarm outputs?Compatible with Penny & Giles LVDTs The DML300 series of digital panel indicators are designed for use with LVDTtransducers. They are ideal for industrial and test applications and feature a fivedigit variable brightness LED display, a fast (125Hz) unscaled analog output formonitoring fast changes,...

Open the catalog to page 3

Type 14.7mm high, high brightness red LED Range -19999 to +99999 (DMP230, DMP240) -1999 to +9999 (DMP210, DMP220) Update Rate 2 per second > Dual slope integrating with auto zeroConversion rate 10 per second Resolution 16 bit + sign (1V) Common mode rejection >150dB Series mode rejection >70dB (50 or 60Hz) > Ranges ձ100mV, 10V Accuracy 0.05% of reading ѱ20V (typically 0.02%) Resolution 1յV (100mV range), 100V (10V range) Input impedance >100M բĦ (mV i/p) >1M Ω (V i/p) > Range 20mA Accuracy 0.05% of reading ѱ4V (typically 0.02%) Resolution 2.0յA Input impedance 5 Ω typical Maximum burden...

Open the catalog to page 4

Type 14.7mm high, high brightness red LED Range -19999 to +99999 Decimal point position User selectable Update rate User selectable 2, 4 or 10 per second Filter User adjustable, 0 (off) to 999 seconds > Input voltage range 0.05V to 5Vrms Gain ranges 1, 5, 10 & 100Automatic or manual gain setting facilities Non linearity < 0.02% Temperature drift < ѱ0.005% FSO / > o C Stability < 0.01% FSO after 15 minutes Transducer supply Selectable 3.0 or 5Vrms @ 25mA Supply frequency User selectable 2.5 or 5.0kHz Measurement resolution Better than 1 part in 120,000 Measurement rate 10 readings per second...

Open the catalog to page 6

Isolation 500Vdc/peak ac Output User selectable 0-10V, 0-20mA or 4-20mA Scaling User selectable (e.g. 4 to 20mA = 3.0 to 5.0mm) Accuracy Better than 0.2% Temperature drift <100ppm / C Response 63% within 32mS, 99% within 100mS Resolution 0.05% (5mV or 0.01mA) Maximum voltage output 11V @ 22mA Maximum current output 22mA @ 18V Maximum load 900 ڢĦ Output damping filter Programmable > Automatically calibrates and matches the indicator to a connected LVDT transducer. TheDML300 reads the transducer's output at any two sensor positions. The two measured values are stored as the calibration...
