Catalog A-1, Filter-Driers / Page 19

Filter-Driers - 17706 Oil Vapor Drier Separator and Steel Muffler

Oil Vapor Drier Separator

The Parker Vapor Drier Separator (VDS Series) removes contaminated oil from a system in addition to solids, acid and moisture. A 1/4" SAE oil drain access fitting is located on the bottom to provide a continuous means of measuring the amount of oil removed from a system, thereby indicating the amount needed to be replaced. The VDS holds up to four ounces of oil and is reusable for up to 50 pounds (22.7 kg) of refrigerant, depending upon contamination levels. For rigid or secure mounting, a side bracket is welded to the body. The VDS can also be hung from a manifold gauge set with the wire strap provided. A model is available with coalescing element for improved oil separation.

Features and Benefits

Dimensions

â–  Oil removal drain fitting â–  Acid and moisture removal â–  3/8" SAE male flare fittings â–  Inlet access valve fitting â–  Mounting bracket
.63REF.2.65 MAX. OVER WELD2.13REF. 7.602.28.31 DIA.REF.2.00REF.REF..25 DIA. REF.2.01 REF.3.761.75 REF.2.50O.D.1.63 OUT

Steel Muffler

Parker’s aftermarket steel muffler (P/N: PM3083-5-4C) is designed to assist with compressor related difficulties, such as noise reduction due to compressor pulsation and/or turbulent gas flow or vibration through the discharge line.

Features

â–  UL/CSA listed for 600 psig (41.4 bar) design pressure for R-410A1/2 ODF Solder â–  â–  Fully welded construction â–  Bi-directional flow â–  Powder coated paint gives maximum cor- rosion resistance of 500 hour salt spray protectionMuffler utilizes 3.0 inch (76.2 mm) diameter â–  shell and is 9.13 inches (232 mm) in length
