Hall Effect, Slide, Specialty and Transducer Switches

HALL EFFECT AND PROPORTIONAL OUTPUT DEVICES

• Non-contacting technology

•

Supply voltage 4.5 VDC to 24 VDC Supply current 8 mAto 10 mA 10 million cycle electrical life

Programmable outputs up to a 5V linear voltage change Moisture proof to IP68. Dust-tight to M8805 Design 2 Choice of termination styles Front or behind panel mounting Variety of case styles Redundant circuit options available

•

SLIDE SWITCH

• Single and double pole, double throw switch configuration •Logic level to 5 amps

• Three position center off with momentary or maintained switch action in any combination

• 100,000 cycles mechanical life

• Dust-tight to M8805 Design 2

• Raised and flush button contours available

• Choice of nine button colors

SPECIALTY SWITCHES

OTTO will customize a standard switch assembly to meet your requirements

Vertically integrated manufacturing capabilities provide flexibility and a cost effective solution for your application Our Engineering staff will work from your specifications or develop drawings and f

specifications that meet your needs OTTO will complete a qualification test plan and acceptance test procedure to ensure your design will meet all of your requirements

TRANSDUCERS

Standard and Custom mounting styles available IAWMIL-S-81619

Enclosure dust-tight to M8805 Design 2 Infinite resolution

Null temp co efficient ± .04% of full scale per degree C

Hysteresis ± .5% of full scale within on second after release

Sensitivity temperature coefficient ±2 % full scale per degree C

Temperature range -55C° thru +85C°

Variety of knob colors and styles available

Short travel, long travel and pushbutton options available

■
