| Hall Effect, Slide, Specialty and Transducer Switches | |||||||||||||||||||
| HALL EFFECT AND PROPORTIONAL OUTPUT DEVICES • Non-contacting technology | |||||||||||||||||||
| • | |||||||||||||||||||
| Supply voltage 4.5 VDC to 24 VDC Supply current 8 mAto 10 mA 10 million cycle electrical life Programmable outputs up to a 5V linear voltage change Moisture proof to IP68. Dust-tight to M8805 Design 2 Choice of termination styles Front or behind panel mounting Variety of case styles Redundant circuit options available | |||||||||||||||||||
| • | |||||||||||||||||||
| SLIDE SWITCH | |||||||||||||||||||
| • Single and double pole, double throw switch configuration •Logic level to 5 amps • Three position center off with momentary or maintained switch action in any combination • 100,000 cycles mechanical life • Dust-tight to M8805 Design 2 • Raised and flush button contours available • Choice of nine button colors | |||||||||||||||||||
| SPECIALTY SWITCHES | |||||||||||||||||||
| OTTO will customize a standard switch assembly to meet your requirements Vertically integrated manufacturing capabilities provide flexibility and a cost effective solution for your application Our Engineering staff will work from your specifications or develop drawings and f specifications that meet your needs OTTO will complete a qualification test plan and acceptance test procedure to ensure your design will meet all of your requirements | |||||||||||||||||||
| TRANSDUCERS | |||||||||||||||||||
| Standard and Custom mounting styles available IAWMIL-S-81619 Enclosure dust-tight to M8805 Design 2 Infinite resolution Null temp co efficient ± .04% of full scale per degree C Hysteresis ± .5% of full scale within on second after release Sensitivity temperature coefficient ±2 % full scale per degree C Temperature range -55C° thru +85C° Variety of knob colors and styles available Short travel, long travel and pushbutton options available | |||||||||||||||||||
| ■ | |||||||||||||||||||
| ■ | |||||||||||||||||||
| ■ | |||||||||||||||||||
