Orwak 3100

Technical specifi cations

Dimensions3100

Front loading baler – compact and effective

A: 1990 mm B: 826 mm C: 693 mm D: 1414 mm E: 661 mm

www.pyramid.se-Orwak 3100-GB-1-0605

‹Perfect for companies with smaller amounts of packaging waste. Bales up to 50 kg are easily handled with the Orwak bale trolley. A reliable partner for better environment and profi table recycling. High capacity on half a square metre fl oor space.

700 x450 mm

Safe operation

Height of front loading aperture gives the operator a comfortable operating position.

Environment station

Loading aperture

Orwak 3100 fi ts in where you need it. Low height together with small external dimensions makes the 3100 your fl exible environment station.

Width: 700 mmHeight: 450 mm

Cycle time

30 secs

Professional press force

3 ton, 30 kN

Bale size

Width: 700 mm Depth: 500 mm Height: 600 mm

Bale weight

Cardboard: Up to 40 kg Plastic: Up to 70 kg

Chamber dimension(internal)

Width: 700 mmDepth: 500 mm Height: 1140 mm

Our promise to You! • Orwak fi nancial solutions• Orwak money back guarantee • Orwak non-stop service

Weight (machine)

Total: 338 kg

Noise level

< 70 db (A)

Protection class

1990 mm

For further information please contact Your local Orwak dealer. IP 55

Operating power

Single Phase 230 V, 50 Hz, 10 A

Professional paint

The Orwak 3100 takes care of most of your waste

Two-part paint and powder coat with phosphatising as base

Paper Plastic foil Semi-dry Waste

Oil volume/type

Cardboard Shrink fi lm Bagged general waste Shredded Plastic professional bags

5,2 l ISO VG 32-68 SAE 10 from +5 °C and warmer

Paper sacks Wet Plastic vessels Juice boxes, Tetra paks

Hydraulical data

Metal Cans PET bottles Special

Working pressure: 110 bar Relief pressure: 140 bar Press force: 3 ton, 30 kN Piston stroke: 640 mm

Aluminium cans Jugs/bottles Industrial steel drums Hazardous waste Food cans Paint cans Other plastics Plastic straps Other metals Steel straps Perfect choice OK Other materials contact us

For more info. contact us or visit our website www.orwak.comWe reserve the right to make changes to specifi cations without prior notice. Bale/bag/bin weights are dependent upon material type. AB Orwak Box 58, SE-576 22 Sävsjö, Sweden Tel: +46 382-157 00, Fax: +46 382-106 07 E-mail: info@orwak.se
