OR 4000 Proven manual tools Sealing with metal seals

The single-lever combination tool for vertical and horizontal strapping For use with PP and PET straps Lightweight, portable, robust High tensioning capacity due to windlass tensioning system – limited only by the breaking strength of the strap

Model Strap type Strap width Strap thickness Weight SealOR 4000.13 PP, PET 13 mm 0.4–0.7 mm 2.3 kg ORP 2100.13 (
1 /
2 “) (.016–.028“) (5.1 lbs) OR 4000.16 PP, PET 16 mm 0.5–1.0 mm 3.4 kg ORP 2300.16 (
5 /
8 “) (.020–.040“) (7.5 lbs) OR 4500.13 PP, PET 13 mm 0.5–0.8 mm 3.4 kg ORP 2100.13 (
1 /
2 “) (.020–.031“) (7.5 lbs)
