STAKPAK LIDS & OPTIONS ORBIS has the most comprehensive offering of covers, including attached-lid or detached lids. Covers protect product from dust and contaminants during storage and transport. ORBIS also offers specific identification options for StakPak containers, including cardholders, labels and hot stamping. Please note that not all options are available on all containers. Contact your ORBIS representative for more details on placement, orientation, availability, minimum order quantities, lead times and set-up charges. Nominal specifications subject to changes without notice. Automotive Components  Bearings  Hardware  Industrial Equipment  Metal Parts  Plastics and Rubber  Resins and Powders 7 www.orbiscorporation.com CONTAINERS WITH ATTACHED LIDS NSOAN1215-7 M 12 12.0 15.0 7.5 9.4 13.0 6.6 3.0 0.48 3,744 305 381 191 239 330 168 1.3 .014 NSOAN1215-9 M 12 12.0 15.0 9.5 9.4 13.0 8.6 3.3 0.62 3,120 305 381 241 239 330 218 1.5 .018 NSOA2415-7 M 6 24.0 15.0 7.5 21.4 13.0 6.6 5.2 1.10 1,872 610 381 191 544 330 168 2.4 .031 NSOAN2415-9 M 6 24.0 15.0 9.5 21.4 13.0 8.6 5.6 1.43 1,560 610 381 241 544 330 218 2.5 .040 NSOAN2415-11.5 M 6 24.0 15.0 11.6 21.4 13.0 10.8 6.5 1.79 1,248 610 381 295 544 330 274 2.9 .051 NSOA2415-14 M 6 24.0 15.0 14.6 21.4 13.0 13.8 7.3 2.28 936 610 381 371 544 330 351 3.3 .065 SOA2411-9 S 8 24.0 11.2 9.5 21.4 9.3 8.5 5.6 2.26 2,080 610 284 241 544 236 216 2.5 .064 NSOA1408-7 M 8 14.0 7.5 6.6 11.1 5.5 5.7 2.0 0.23 5,616 (32 x 30) 355 191 167 281 139 144 0.9 0.70 DETACHED LIDS RCSO1207-1 - - - - 12.0 7.4 - - - - 0.4 - - 305 188 0.2 - - RCSO1215-1 - - - - 12.0 15.0 - - - - 0.8 - - 305 381 0.4 - - RCSO2415-1 - - - - 24.0 15.0 - - - - 2.1 - - 610 381 1.0 - - RCSO2411-1 - - - - 24.0 11.2 - - - - 1.0 - - 610 284 0.5 - - RCSO2422-1** - - - - 24.0 22.4 - - - - 2.6 - - 610 569 1.2 - - RCSO3215-1 - - - - 32.0 15.0 - - - - 1.8 - - 813 381 - - - 0.8 - - Outside Dimensions L W Model Inside Dimensions (Bottom) H L W Product Clearance* Volume (cu. ft.) 53’ Trailer Quantity 50” Unit Loads Weight (lb.) +/- 3% Containers per Layer 45”x 48” Smooth (M) Bottom Style Reinforced (R) Specifications (Upper Dimensions: English, Lower Dimensions: Metric) Textured (S) Outside dimensional tolerance of +/- .05”. * Patented process #5,625,858 owned by The Kennedy Group CHSO491 Label Placard 4.5 x 6.5* CHSO291 3.3 8.5 Polypropylene 4” NSOs 4.0 x 8.3 CHSO292 3.3 8.5 Polypropylene 4” MSOs 4.0 x 8.3 CHSO391 3.8 8.5 Polypropylene 5” 4.0 x 8.3 CHSO46 4.6 7.7 Polypropylene 2411-9 (Short Side) 4.0 x 6.0 CHSO491 4.6 8.5 Polypropylene 7” & taller 4.0 x 8.3 CHFC49 4.0 8.4 HDPE Long Boxes 4.0 x 8.3 Placard* 3.0 5.0 Adhesive 4” and 5” N/A Placard* 4.5 6.5 Adhesive 7” and taller N/A CHV73-NFH2 3.3 7.8 Adhesive Folding Containers 4.0 x 6.0 CHV81-2AH1 3.3 7.8 Adhesive Folding Containers 4.0 x 6.0 Model Outside Dimensions H L Description Fits Container Heights Fits Card Size Hot Stamp identification is also available for StakPaks. The original artwork must be supplied to ORBIS at the time of the order. Size and available location of the hot stamp will vary for each container. Minimum shipment is required. Cardholders are manufactured in polyethylene and quickly snap onto StakPaks, for instant identification. These cardholders, available in a wide variety of sizes to fit on different containers, accommodate removable cards with bar codes and other identification documents. StakPaks accommodate the Label Placards, developed by The Kennedy Group. Completely removable and replaceable, these label placards accommodate all types of labels.They are available in two sizes:  2.0” x 6.5” for 4” StakPaks  4.5” x 6.5” for StakPaks 5” or taller StakPaks can also accommodate the Smart Placard™ Radio Frequency Identification (RFID) system, developed by The Kennedy Group. This solution stores information for the efficient tracking and identification of containers, pallets and other material handling products. The reusable system provides longevity for multiple trips to reduce the cost per tag, while allowing easy removal and replacement of labels. Customized Hot Stamp Identification Options * When containers are stacked on top of each other, approximately 1/2” is lost to nesting. Example: Bottom container in a stack is 7.5” in height. Containers of the same height stacked on top of it are 7.0” in height. ** Does not fit SO2422-7 or SO2422-9.Works with NSO containers in the same footprint. HAND-HELD CONTAINERS
