ORBIS 2009_Product and Service Guide - ORBIS - #39

Text version of the page

The medium-duty BulkPak® 3230 KD Series containers are ideal for high density small to medium sized parts and are perfect for tight working spaces. Designed to hold 2,000 lbs, these containers are built for medium-duty applications. Custom protective dunnage is available for all ORBIS BulkPak containers. (See pp. 63-66.) 37 www.orbiscorporation.com Non-sequential wall hinge design allows sidewalls to completely collapse, preventing wall and hinge damage. KD3230-34 KD3230-34 Positive stacking of one container on another to reduce floorspace. Need additional part protection? Work with ORBIS Sales Engineers to develop custom protective dunnage. See pp. 63-66 for more information. Large, spring-loaded ergonomic latches make collapsing containers and opening/closing access doors extremely easy. Available in two heights: 25” and 34” All dimensions and specifications are approximate. Performance characteristics are based on uniform static loads and may be affected by distribution of load, handling methods, number and type of access doors and temperatures beyond the range of 0° F to 120° F. Cardholder BulkPak Covers Placard Board* Label Placard* Multiple access door configurations: 0, 1 or 2 doors on the 32” side All-plastic picture frame bottom. ID Plate Access Door Openings 53’ Truckload Quantities (w/o covers) Height Width KD3230-25 3.5 4.2 11.1 7.3 294 168 480 252 88.9 106.7 281.9 185.4 N/A N/A N/A N/A KD3230-34 3.5 4.2 11.1 7.3 294 126 480 189 88.9 106.7 281.9 185.4 N/A N/A N/A N/A Model Collapsed Outside Dimensions L (A) W (B) Inside Dimensions Collapsed Model Height Container Capacity (lb.) Weight (lb.) Internal Volume (cu. ft.) Return Ratio Assembled H (C) L (D) W (E) Product Clearance (F) CONTAINERS KD3230-25 32.0 30.0 25.0 29.2 27.3 18.1 13.1 2,000 68.0 8.40 6 high 4 high 2.3:1 10.5 N/A 18.0 N/A 812.8 762.0 635.0 741.7 693.4 459.7 332.7 900.0 30.6 0.24 N/A N/A N/A 266.7 N/A 457.2 N/A KD3230-34 32.0 30.0 34.0 29.2 27.3 27.1 13.1 2,000 85.0 12.5 6 high 3 high 2.5:1 15.0 N/A 18.0 N/A 812.8 762.0 863.6 741.7 693.4 688.3 332.7 900.0 38.3 0.35 N/A N/A N/A 381.0 N/A 457.2 N/A COVER CKD3230 32.7 30.6 2.0 32.5 30.8 1.7 N/A N/A 11.0 N/A N/A N/A N/A N/A N/A N/A N/A 830.6 777.2 50.8 825.5 782.3 43.2 N/A N/A 4.9 N/A N/A N/A N/A N/A N/A N/A N/A Fork Openings Height Width Long Side (H) Short Side (J) Long Side (G) Short Side (I) Specifications (continued) BulkPak® 3230 KD Container Specifications (Upper Dimensions: English, Lower Dimensions: Metric) Maximum Loaded Stack Static Dynamic Long Side Short Side Long Side Short Side 40’ Container Quantities (w/o covers) Collapsed Assembled *Patented process #5,628,858 owned by The Kennedy Group. 32”x 30”MEDIUM-DUTY BULKPAK® Automotive Components  Bearings  Hardware  Industrial Equipment  Metal Parts  Plastics and Rubber  Tools BULK CONTAINERS Planning a new packaging program? Talk to your ORBIS Sales Representative about Engineering Services to support your rightsizing efforts. See pp. 1-2 for more information.
