24”X 20”FLIPAK CONTAINERS
The 24” x 20” family of FliPak® containers are used in applications such as general merchandise and part distribution. These
containers stack on a 40” x 48” pallet.
LARGE VOLUME FLIPAK CONTAINERS
27 www.orbiscorporation.com
HAND-HELD
CONTAINERS
L L L L
Outside Dimensions
Top
Inside Dimensions
Footprint
Total
Container
Height
Product
Clearance
Container
Weight
(lb.)
Bottom Top Bottom
W W W W
27 x 17 x 12 FP242 26.9 17.1 24.3 14.6 25.3 15.5 23.4 13.9 12.6 11.5 8.2
FPN242 27.5 16.9 24.4 14.6 25.3 15.5 23.6 13.8 12.6 11.5 8.9
28 x 20 x 12 FP30 28.0 20.6 25.0 18.0 26.0 19.0 24.7 17.8 12.5 11.0 10.0
28 x 20 x 15 FP402 27.9 20.6 25.8 18.7 26.0 19.0 25.0 18.0 15.6 14.0 12.7
FPN402 28.3 20.4 25.8 18.7 26.0 19.5 25.0 18.0 15.1 14.0 13.5
30 x 22 x 20 FP60 30.0 22.0 27.4 19.4 28.7 20.8 26.7 18.7 20.5 18.8 17.0
39 x 14 x 13 FP32 39.0 14.0 36.3 11.3 37.5 12.5 36.0 11.0 13.0 12.1 10.4
Model
FliPak® Specifications All dimensions in inches, unless specified.
L L L L
Outside Dimensions
Top
Inside Dimensions
Footprint
Total
Container
Height
Product
Clearance
Container
Weight
(lb.)
Bottom Top Bottom
W W W W
12 x 10 x 7 FP03 11.8 9.8 9.3 7.0 10.1 7.8 8.7 6.4 7.7 6.5 2.1
20 x 12 x 7 FP075 19.7 11.8 16.9 9.3 17.7 10.1 16.2 8.6 7.3 6.0 3.4
24 x 20 x 12 FP261* 23.9 19.6 21.1 17.1 22.2 18.2 20.6 16.5 12.6 11.5 8.4
Model
FliPak® Specifications All dimensions in inches, unless specified.
Plastic Hinge Metal Hinge
Two hinge styles available
on selected containers:
This family of FliPak® containers are ideal for large volume applications, such as automotive aftermarket, hardware and general distribution.
Choose from 27” x 17” to 39” x 14” container footprints.
FPN402 FP242
FP402
FP38
FP60
FP30
Full and half size
containers for
system flexibility
* Available with rail for document storage and transportation.
Please ask your ORBIS Sales Representative about the FPR261.
FP03 on
FP075
FP261
on dolly
Healthy and Beauty Care Items Pharmaceutical Products Food Periodicals Apparel Automotive Aftermarket
