Distribution Containers Outside Dimensions L W Weight (lb.) Volume (cu. ft.) Nest Model Ratio Inside Dimensions L W Total Height Product Clearance Top Bottom Top Bottom L W L W Stacks with cover and nests when empty. Snap tight covers available for secure storage/transport and product protection. Reinforced covers and ribs add strength and ensure long life. Truckload Quantity 53’ Trailer Ventilation minimizes freezing time and allows temperature control. Nestable, for space efficiency. Smooth interior for easy cleaning. NOX2416-8 with CNOX2416-3 cover SO2726-1 CT1080/1085 NO2416-11 with CNO2416-1 cover NOX2416-8 with CNOX2416-3 cover DISTRIBUTION CONTAINERS NOX2416-8 24.0 16.0 22.0 14.0 21.7 15.2 20.3 12.7 8.0 7.0 4.2 1.5 4.0:1 CNOX2416-3 175 4,900 NO2416-11 24.0 16.0 22.2 14.2 23.5 15.3 20.1 13.1 10.7 10.7 4.6 1.9 4.9:1 CNO2416-1 150 4,500* N 2416-11 NPL 747 24.0 16.0 22.2 14.2 23.7 15.2 20.1 13.1 10.7 10.5 4.5 1.9 4.8:1 NPL1101 180 5,040 NO2416-11 NPL 748 24.0 16.0 22.0 14.2 23.7 15.2 20.1 13.1 10.7 10.5 5.5 1.9 4.8:1 NPL1101 180 5,040 NO2416-8 NPL 749 24.0 16.0 21.6 12.6 23.7 15.2 20.0 13.1 8.0 7.7 4.2 1.3 4.0:1 NPL1101 210 5,600 NO2416-9 NPL 750 24.0 16.0 22.0 14.2 23.7 15.2 20.1 13.1 8.7 8.5 3.8 1.5 4.0:1 NPL1100 220 6,660 COVERS CNOX2416-3 24.0 16.0 N/A N/A N/A N/A N/A N/A 1.5 N/A 2.2 N/A N/A N/A N/A N/A CNO2416-1 24.3 16.3 N/A N/A N/A N/A N/A N/A 1.8 N/A 2.2 N/A N/A N/A N/A N/A CNO2416-1 NPL1100 24.50 16.70 N/A N/A N/A N/A N/A N/A 1.8 N/A 2.2 N/A N/A N/A 440 N/A CNO2416-1 NPL1101 24.25 16.25 N/A N/A N/A N/A N/A N/A 1.7 N/A 2.3 N/A N/A N/A 500 N/A CHILL TRAYS CT1080 29.2 26.2 29.1 25.9 28.3 24.9 27.5 24.6 9.0 7.3 7.4 N/A 2.0:1 N/A N/A 1,240* CT1085 29.2 26.2 29.1 25.9 28.3 24.9 27.5 24.6 9.3 7.8 7.7 N/A 2.0:1 N/A N/A 1,386 SO2726-1 27.6 26.0 27.6 26.0 N/A N/A 27.2 25.4 2.3 N/A 4.3 N/A 2.0:1 N/A N/A N/A * Estimated truckload quantity, please contact ORBIS for specific information. Chill Trays Specifications All dimensions in inches unless specified. 17 www.orbiscorporation.com POULTRY CONTAINERS Chicken  Red Meat  Seafood  Turkey Distribution Containers and Chill Trays are used in many types of fresh food handling and processing applications. These durable, injection-molded reusable containers provide a long service life for poultry, meat and seafood from the processing plant to distribution and retail display. Distribution Containers are available in 3 standard heights, with optional snap-tight covers. Optional drain holes are available for moisture control. Distribution Containers (NO/NOX/NPL) are compatible with standard 40 x 48 CISS LP Pallet (See p. 82) and 40 x 48 NPL 352 (p. 83). Multiple identification options and accessories available. Chill Trays are available in standard 26” x 29” footprint. Fully ventilated design speeds cooling. All products are available in FDA-approved materials. If FDA materials are required, please specify when requesting a quote. Cover NO2416-9 NPL 750 with CNO2416-1 NPL1100 cover Withstands temperatures from -20° to 120° F. Deep pocket handles for use with gloves. Pallet Quantity HAND-HELD CONTAINERS NO/NOX/NPL 24 x 20 40 x 48 CISS LP p. 82 Compatible Pa l l e t s Containers Nestable Pallets 40 x 48 NPL 352 p. 83 24 x 20 Planning a new packaging program? Talk to your ORBIS Sales Representative about Engineering Services to identify your needs and design a reusable packaging program to add efficiency to your entire system. See pp. 1-2 for more information 40x48 CISS LP pallet (See p. 82.) O
