| + Basic Product Specifications | |||||||||||||||||||
| OPT6125_001 | |||||||||||||||||||
| Regulatory & Safety Product compliance: EN 55022, EN 55024 Sold separately Power supply 230V-5V/500mA (for Keyboard Wedge, RS232) Models Interface versions: RS232, Keyboard Wedge, USB Color versions: Black, White | |||||||||||||||||||
| Operating indicators Visual: 1 LED (red/green/orange) Non-visual: Buzzer Operating keys Entry options: 1 scan key Communication RS232: DB9 F connector with external power supply Keyboard Wedge: XT/AT and PS2, DIN5 F/M connector, MiniDIN6 F/M connector with external power supply USB: Ver. 1.1, HID, USB-A connector Power Voltage requirement: 5 V ± 5% Current consumption: Max. 100 mA Idle current: 30 mA Barcode scanner Optics Light source: 630 nm red LED Scan method: 2k element CCD Scan rate: 200 scans/sec. Trigger mode: Manual Min. resolution at PCS 0.9: 0.127 mm / 5 mil Min. PCS value: 0.45 Depth of field: At PCS 0.9 EAN13 0 - 30 mm / 0 - 1.18 in (0.33 mm / 13 mil) Supported Symbologies Barcode (1D): JAN/UPC/EAN incl. add on, Code 39, Code 93, Code 128, GS1-128 (EAN-128), IATA, ISBN-ISSN, Industrial 2of5, Interleaved 2of5, Matrix 2of5, MSI/Plessey, Telepen, Tri-Optic, S-Code, UK/Plessey Postal code: Chinese Post Durability Temperature in operation: 0 to 40 °C / 32 to 104 °F (5 to 40 °C / 41 to 104 °F USB interface) Temperature in storage: -20 to 60 °C / -4 to 140 °F Humidity in operation: 20 - 80 % (non-condensing) Humidity in storage: 20 - 90 % (non-condensing) Ambient light immunity: White 2,000 lx max, Fluorescent 3,000 lx max Drop test: 1.5 m / 5 ft drop onto concrete surface Vibration test: 10 - 100 Hz with 2G for 1 hour Physical Dimensions (w x h x d): 72 x 152 x 47 mm / 2.83 x 5.98 x 1.85 in Weight body: Ca. 90 g / 3.2 oz (excl. cable) Case: ABS, Black or White | |||||||||||||||||||
| Copyright Opticon. All rights reserved. This information is subject to change without prior notice. | |||||||||||||||||||
| - The Netherlands: Hoofddorp - France: ISSY Les Moulineaux CEDEX - Germany: Dietzenbach - Italy: Castel Maggiore (BO) - Spain: Valencia - Sweden: Jδrfδlla - United Kingdom: Luton, Bedfordshire - U.S.A.: Orangeburg, NY - Seattle, WA - Japan: Warabi City | - Taiwan: Taipei - P.R.China: Shanghai - Australia: Kariong | ||||||||||||||||||
| Opticon Sensors Europe B.V. European headquarters Opaallaan 35 2132 XV Hoofddorp The Netherlands phone: +31 (0)23-5692700 fax: +31 (0)23-5638266 email: sales@opticon.com internet: www.opticon.com | |||||||||||||||||||
