| + Basic Product Specifications | ||||||||||||||||||||
| OPL7734_001 | ||||||||||||||||||||
| Operation CPU: 16-bit CMOS Memory FlashROM: 256 kB RAM: 32 kB fastRAM Operating indicators Visual: 1 LED (red/green/orange) Non-visual: Buzzer Operating keys Entry options: 1 scan key Communication IEEE 802.15.4: Output power class 2, range up to 30 m, 1 to 1 / 8 to 1 connection (8 scanners to 1 CRD-7734), encryption Power Rechargeable battery: Lithium-Ion 3.7 V nom. 600 mAh Operating time: 50 hours (1 scan / 5 sec) Charging method: Separate cradle CRD7734 Barcode scanner Optics Light source: 650 nm visible laser diode Scan rate: 100 scans/sec Trigger mode: Manual Reading pitch angle: -20 to 0°, 0 to +20° Reading skew angle: -50 to -8°, +8 to +50° Reading tilt angle: -50 to -8°, +8 to +50° Curvature: R>15 mm (EAN8), R>20 mm (EAN13) Min. resolution at PCS 0.9: 0.15 mm / 6 mil Min. PCS value: 0.45 Depth of field: At PCS 0.9 Code 39 50 - 360 mm / 1.97 - 14.17 in (1.0 mm / 39 mil), 30 - 270 mm / 1.18 - 10.63 in (0.5 mm / 20 mil), 30 - 140 mm / 1.18 - 5.51 in (0.25 mm / 10 mil), 30 - 70 mm / 1.18 - 2.76 in (0.15 mm / 6 mil) Supported Symbologies Barcode (1D): JAN/UPC/EAN incl. add on, Codabar/ NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISMN-ISSN, Matrix 2of5, MSI/ Plessey, S-Code,Telepen, Tri-Optic, UK/Plessey Postal code: Chinese Post, Korean Postal Authority code 2D code: Composite codes, MicroPDF417, PDF417 | Durability Temperature in operation: 0 to 40 °C / 32 to 104 °F Temperature in storage: -20 to 60 °C / -4 to 140 °F Humidity in operation: 25 - 85 % (non-condensing) Humidity in storage: 20 - 90 % (non-condensing) Ambient light immunity: Fluorescent 3,000 Ix max, Direct sun 50,000 Ix max, Incandescent 3,000 Ix max Drop test: 1.5 m / 5 ft drop onto concrete surface Physical Dimensions (w x h x d): 55 x 150 x 115 mm / 2.17 x 5.91 x 4.53 in Weight body: Ca. 130 g / 5 oz (incl. battery) Case: ABS, Black or White Regulatory & Safety Product compliance: CE, FCC, VCCI, RoHS, JIS-C-6802 Class 2 Sold separately CRD7734 network cradle | |||||||||||||||||||
| Copyright Opticon. All rights reserved. This information is subject to change without prior notice. | ||||||||||||||||||||
| - The Netherlands: Hoofddorp - France: ISSY Les Moulineaux CEDEX - Germany: Dietzenbach - Italy: Castel Maggiore (BO) - Spain: Valencia - Sweden: Jδrfδlla - United Kingdom: Luton, Bedfordshire - U.S.A.: Orangeburg, NY - Seattle, WA - Japan: Warabi City | - Taiwan: Taipei - P.R.China: Shanghai - Australia: Kariong | |||||||||||||||||||
| Opticon Sensors Europe B.V. European headquarters Opaallaan 35 2132 XV Hoofddorp The Netherlands phone: +31 (0)23-5692700 fax: +31 (0)23-5638266 email: sales@opticon.com internet: www.opticon.com | ||||||||||||||||||||
