OPTEX Product Information

Non-Contact Thermometer Separate Sensor BS Series

THERMO-HUNTER

BUILT-IN2

SPECIFICATIONS


Sensor head				Amplifier
Model	BS-30T	BS-05T	BS-02T	Model	BS-V BS-A
Field of view	03O/5OOmm	05/1OOmm	02/5Omm	Measuring range	0 to 500"C
Optics	Silicon lens			Display range	-20 to 520"C
Sensing element/Wavelength	Thermopile/8 to 14nm			Response time	500msec./90%
Sighting method	N/A		Coaxial laser marker (Class 2)	Accuracy (e 1.0)	±1% of reading value or ±2"C whichever is greater
Sighting method	N/A		Coaxial laser marker (Class 2)	Repeatability	±1"C of reading value
Ambient temperature	0 to 65"C (0 to 150"C: with optional cooling jacket)		0 to 50"C	Display resolution	rc
Ambient temperature	0 to 65"C (0 to 150"C: with optional cooling jacket)		0 to 50"C	Analog output	1mV/"C 4 —20mA
Environmental humidity	35 to 85%RH (without dew condensation)			Analog output	1mV/"C 4 —20mA
Environmental humidity	35 to 85%RH (without dew condensation)			Output resolution	0.2"C
Storage temperature	-20 to 70"C -20 to 60"C			Output resolution	0.2"C
Storage temperature	-20 to 70"C -20 to 60"C			Emlsslvlty ratio (e) adjustment	O.IOto 1.20 (0.01/1 step)
Vibration resistance	3G (20 — 50Hz, in accordance with JIS C0911)			Emlsslvlty ratio (e) adjustment	O.IOto 1.20 (0.01/1 step)
Vibration resistance	3G (20 — 50Hz, in accordance with JIS C0911)			Delay setting	1 (0.5sec) to 200 (approx. 10sec) variable
Water resistance	IP67			Delay setting	1 (0.5sec) to 200 (approx. 10sec) variable
Water resistance	IP67			Power supply/Current consumption	DC12 — 24V±10%/M ax 100mA
Weight	300g 400g			Power supply/Current consumption	DC12 — 24V±10%/M ax 100mA
Weight	300g 400g			Ambient temperature	0 to 50"C
Optional accessories	Refer to the Optional Accessory Table of the previous page			Ambient temperature	0 to 50"C
Optional accessories	Refer to the Optional Accessory Table of the previous page			Environmental humidity	35 to 85%RH (without dew condensation)
* A sensor and an amplifier form one complete set. They do not function individually. " Specifications may change without prior notice.				Environmental humidity	35 to 85%RH (without dew condensation)
				Storage temperature	-20 to 60'C
				Vibration resistance	3G (20 — 50Hz, in accordance with J IS C0911)
				Water resistance	IP65
				Weight	320g
				Standard accessories	Fixture x 1, M4screwx2

Separate Sensor for Flexible Installation

3 Different Sensor Models for Standard Focus, Narrow Focus and Fine Spot Measurement

Non-Contact Thermometer

THERMO-HUNTER

BUILT-IN2

Separate Sensor: BS Series

DIMENSIONS

[Unit: mm]

¹ Sensor Head BS-30T/BS-05T

¹ Air/Water Cooling Jacket (option)

BS-WP1 I. 45

Connector cable

(for BS-30/05T) £ Mounting fixture


17	7j	1	-----rri 11 h—*i ~**
--ë	Í		-ITT=L±\|-H P Cable length	r- _t
			-ITT=L±\|-H P Cable length	r- _t

Caution label Connector cable

\ Water outlet (PF1/8) Water inlet (PF1/8)

BS-02T

Cable length

¹ Amplifier BS-A/BS-V

Safety Guidelines

Amplifier Fixture

W1/4Tap

BS-02T is Class 2 laser products.


	ggggggggggggggggg

		n

DO NOT STARE INTO BEAM

LASER DIODE POWER MAX1 .OmW WAVE LENGTH67Onm CLASS2 LASER PRODUCT

Products mentioned In this catalogue are equipped with Class 2 laser. In case of re-export to foreign countries, please confirm the relevant regulation for laser products In the destination country.


	^WARNING	Do not look into the laser nor direct it toward the eyes. Even the reflection is harmful. Laser may cause eye injury or damage your health.
	/^CAUTION	This product is not a clinical thermometer; therefore, it cannot be used for medical purposes.
	Environmental Warnings

Screw holes M4 x 8mm depth

©KEEP THE THERMOMETER AWAY FROM DIRECT SUNLIGHT, DUST, HIGH TEMPERATURES AND HIGH HUMIDITY WHILE IN USE AND STORAGE. This may cause irreparable damage or incorrect measurement.

©DO NOT EXPOSE THE THERMOMETER TO SUDDEN TEMPERATURE CHANGES.

Sudden temperature change of the environment may cause incorrect measurement. In such cases, wait until the thermometer reaches steady temperature before taking measurement.

©KEEP THE THERMOMETER AWAY FROM STRONG ELECTROMAGNETIC SOURCES, CORROSIVE OR EXPLOSIVE GASES. This may cause irreparable damage or incorrect measurement.

• Sensor Mounting Bracket (option)

NB-SH30A (for BS-30/05T)

NB-SH40A (forBS-02T)



	-4—	-1


				(Ti
	I


	I 4	2 J	^,030
		J	Hh
84

Usage Warnings

0AVOID MEASURING SHINY SURFACES.

Shiny surfaces reflect radiation from surrounding objects. Although the emissivity ratio can be adjusted to compensate for this problem, accurate measurement is difficult.

0USE THE CORRECT VOLTAGE. Applying voltages other than 12-24VDC may cause short-circuit, damages, fire or injury. In such cases, turn the power off immediately.

©DO NOT LET THE THERMOMETER TOUCH THE OBJECTS THAT IS BEING MEASURED. The unit is a non-contact thermometer. Touching or getting too close to the objects with high temperatures may cause irreparable damage or incorrect measurement.

<S>DO NOT TOUCH THE LENS.

Do not touch the lens with anything hard or things with sharp points, which may dameage the lens. A ^damaged lens causes incorrect measurement.

KEEP THE THERMOMETER AWAY FROM CHARGED OBJECTS. This may cause irreparable damage or incorrect measurement.

12.5


	-1-	\ 2-09
	I	\ 2-09
	*I ⁸⁴*

Measuring range: 0 to 500°C

Quick response: 500msec

Amplifier unit with integrated digital display

e-TEACH function for easy emissivity adjustment

Analog output: 4—20mA or 1mV/°C

BS-30T

BS-05T

BS-02T

BS-A

BS-V

Sensor

Amplifier


	ISf	UKAS quality management
		001

□PTEX

OPTEX CO., LTD.

4-7-5 Nionohama Otsu 520-0801 Japan TEL +81-77-524-6049 FAX +81-77-524-1491 URL: www.optex.co.jp

No. 74040-03-09785-0306

Note: A sensor and an amplifier form one complete set. They do not function individually.
