For latest updates please visit our website: www.ophir-spiricon.com 81 01.01.2010 2.1.2 Nova ll Versatile Laser Power/Energy Meter Compatible with all Ophir thermal, pyroelectric and photodiode sensors Large high definition LCD display Choice of digital or analog needle display 2 position kickstand Backlighting and rechargeable battery Analog output Log every point at up to 4000Hz with pyro sensors Non volatile data storage up to 54,000 points Laser tuning screen and power and energy log USB and RS232 interfaces with StarLab and StarCom PC applications, LabVIEW driver and ActiveX control (see pages 95-99) NIST traceable and CE marked Soft keys and menu driven functions with on-line help Many software features such and density, min/max, scaling etc. The Nova II is the most versatile and sophisticated handheld laser power/energy meter on the market. Just plug in one of the many Ophir sensors and you have a whole measurement laboratory at your fingertips. Besides measuring power or energy from pJ and pW to hundreds of Joules and thousands of Watts, the Nova II has many on-board features such as laser tuning, data logging, graphing, normalize, power or energy density units, attenuation scaling, max and min limits. For those who prefer an analog display, the Nova II can also display the power or energy with a high resolution simulated analog needle display. The Nova II can be operated either by battery or from an AC source with the charger plugged in at all times. Its backlight allows illumination of the power meter in low light conditions. The built-in USB and RS232 interfaces and StarLab and StarCom PC software allow on-line processing of data or processing previously stored data; results are displayed graphically on a PC. To support PC interfacing, LabVIEW drivers and ActiveX controls are provided. Selected Screens Digital Power Screen CW industrial, medical and scientific lasers pW to Multi KW with appropriate sensors Can average over selected period. Useful for unstable lasers. Fast response bar graph Ê Ê Ê Ê Ê Ê Ê Ê Ê Ê Ê Ê Ê Ê Ê Ê Ê Selected laser wavelength Access further functions Change to energy Zoom bar graph Subtract offset Detailed help Power range Average period Sensor type and S/N Selected range 2.1.2 Power Meters StarLab Software StarCom SoftWare LabVIEW
