Note: Specifi cations subject to change without notice. OMAX Corporation 21409 72nd Ave South, Kent, WA 98032 253-872-2300 tel 253-872-6190 fax 1-800-838-0343 toll-free WWW.OMAX.COM website Printed in the U.S.A © March 2008 All rights reserved. OC-0025 OMAX 60120 JetMachining Center Options • Precision Optical Locator • OMAX Solids Removal System (SRS) • Tilt-A-Jet® for taper-free parts • Water-only MAXJET 5 nozzle for cutting soft materials • OMAX MAXJET 5 MiniJet Nozzle Assembly • Waterjet Brick • Weir Tank • Z-Axis Drill • Manual Tilt Z Abrasivejet • Terrain Follower Catcher Tank Nozzle Machine Dimensions Footprint 225” x 110” (5715 mm x 2794 mm) Weight (tank empty) 6200 lbs (2818 kg) Height 115” (2921 mm) Operating Weight 23,200 lbs (10545 kg) Work Envelope X-Y Travel 126” x 62” (3200 mm x 1575 mm) Table Size 144” x 77” (3656 mm x 1956 mm) Material Support Slats 4” x 1/8” Galvanized Steel Maximum Supported Material Load 250 lbs/sq. ft. (1,200 kg/sq. meter) (Optional accessories may reduce travel. Contact OMAX for information.) Computer Control System Hardware Personal computer Control Software Integrated CAD/CAM system directly uses .DXF fi les Drive Description • Closed loop, digital drives • Brushless servo motors • Pre-loaded ballscrew with recirculating ball bearings and hardened precision ground ways in Y-Axis • Bridge style Y-Axis • Traction drive with linear encoder in X-Axis • Motor controlled precision Z-Axis Accuracy of Motion at 70° F Ball Bar Circularity (Over 12”) At Max. Traverse Velocity ±0.003” (±0.08 mm) Repeatability ±0.002” (±0.051 mm) Squareness 0.002” per foot (0.17 mm/m) Straightness 0.003” per foot (0.25 mm/m) Backlash 0.0007” max (0.018 mm) Speed • 180 inches per minute standard (4572 mm/min) Electrical Requirements • 3-Phase, 380-480 VAC ±10%, 50-60 Hz (Note: Contact OMAX for detailed utility requirements. Pumps are built to meet UL and CE specifi cations.) Pump Options • 30 horsepower, 50,000 psi (3500 bar) • 40 horsepower, 55,000 psi (3850 bar) Noise Level • Below 80 dBA for submerged cutting About OMAX OMAX has the industry leading patented abrasivejet controller with a built-in expert system. The OMAX Software makes it easy to machine precision parts as fast as possible at the lowest cost. JetMachining is ideal for short-run part production, just-in-time manufacturing, tooling, and prototype part development. It requires no tool changes or complex fi xturing, so you can reduce setup times by at least 50%. For more information on what other OMAX products and accessories can do for you, call us today at 800-838-0343 or visit our website at www.omax.com. Controller Y-Axis Ball Screw and Precision Ground Rails are Completely Enclosed Inside Bellows
