Text version of the page
Dual Pressure Compensator
“P-2--” “P-D--”
Triple Pressure Compensator
“P-3--”
Similar to “P-1NN” but provides two independently adjustable pressure compensated deliveries as selected by an integral solenoid. Similar to “P-1NN” but, provides three independentlyadjustable pressure compensated deliveries as selected by integral solenoids.Pump Controls*
Dual Soft Start
#Triple Soft Start
#“P-E--”
Pump starts “softly” similar to “P-C--” but then provides two independently adjustable pressure compensated deliveries as selected by an integral solenoid. Similar to “P-C--” but, after the soft start the unit provides three independently adjustable pressure compensated deliveries as selected by an integral solenoids.*
Be sure system and pumps are protected against over loads with a high pressure relief valve. #Not to be used for decompressing system.
