OBO-DAB damp-proof junction boxes

50

M

58.5 23 halogen-free chlorinefluorinebromine Type Colour Cartonqty Packqty Weightkg/100 Ord. no. 101.6 UF 3030 5 5 38.000 31.000 2001241 2001268 101.6 (fixing holes) 122.4 Accessories available: B 100 M ...: Protection IP 54, rated voltage 660 V,nominal cross-section 10 mm Terminal stripsKL 100see page 30Push-in sealsEDVS 25see page 27
2 4 fixing holes for screws up to 5 mm 4 lid screws, sealable with sealing caps supplied, 6 breakout entries 25.5 mm Ø (M25), with 4 cable entries EDVS 25 for cable diameters 7.5-22 mmClear internal dimensions: 108 x 108 x 51 B 100 M: With five-pole terminal strip KL 100 of melamine with clamp terminals for max. three 10 mm
2 conductors per terminal B 100 M empty: Without terminal strip UF Duroplast/aminoplast 131.5 (UF), light grey (RAL 7035),difficult to ignite 50

M

29.5 70 halogen-free chlorinefluorinebromine Type Colour Cartonqty Packqty Weightkg/100 Ord. no. UF
50 143 1010 1 1 70.000 55.000 2001292 2001306
118 (fixing holes) 143 (fixing holes) 168 Accessories available: Push-in sealsEDVS 32see page 27 B 160 M ...: Protection IP 54, rated voltage 660 V,nominal cross-section 16 mm
2 4 fixing holes for screws up to 5.5 mm4 lid screws, sealable with sealing caps supplied, 8 breakout entries 32.5 mm Ø (M32),with 4 cable entries EDVS 32 for cable diameter 12-30 mmClear internal dimensions: 150 x 125 x 61 B 160 M: With five-pole terminal strip KL 160 of melamine with clamp terminals for max. three 16 mm
2 conductors per terminal B 160 M empty: Without terminal strip UF Duroplast/aminoplast 131.5 (UF), light grey (RAL 7035),difficult to ignite Please always state the ordering number when ordering.
