OBO
BETTERMANN
Brass cable glands
E
Type
Thread
Colour
Carton
Pack
Weight
Ord. no.
qty
qty
kg/100
Ms
160/GMS
Pg 9
nickel-plated
800
50
1.060
2080 70 2
160/GMS
Pg 11
nickel-plated
500
25
1.690
2080 72 9
160/GMS
Pg 13.5
nickel-plated
600
50
2.350
2080 74 5
160/GMS
Pg16
nickel-plated
400
25
2.700
2080 76 1
160/GMS
Pg21
nickel-plated
300
25
4.560
2080 79 6
160/GMS
Pg29
nickel-plated
120
10
7.800
2080 82 6
Nom. size
Sealing range D
SS
E ca
D1
L
L1
L2
L3
G
Type 160/GMS
mm
mm
mm
max
mm
mm
mm
mm
mm
Pg 7
13
14.3
14
15
5
10
2.5
Pg 9
; - 9.5
15
16.6
17
16
6
10.5
2.5
Pg 11
10 -11.5
18
20
20
17
6
11
3
Pg 13.5
11 -13
20
22.2
22
18
6.5
12.5
3
Pg 16
13 -15
22
24.4
24
19
6.5
13.5
3
Pg 21
19.5-20.5
28
31.2
30
22
7
15
3.5
Pg 29
28 -29.5
37
41
39
24
8
16.5
4
With large gasket
•Prices to DEL quotation; see Notes on Materials
Accessories available:
Thread entry seals
170 (Flat)
171 (O-ring)
160/GMS: cable gland with round intermediate socket, Form C 5 to DIN 46320
With Pg connecting thread to DIN 40430
Compression rings of steel, electro-galvanised and yellow-chromated seal of NR/SBR
Degree of protection: with seal IP65, without IP54 With single gasket, with large internal diameter
see page 76 see page 77
Brass, nickel-plated
Ms
E
Type
Thread
Colour
Carton
Pack
Weight
Ord. no.
qty
qty
kg/100
Ms
161/MS
Pg 11
nickel-plated
800
50
1.915
2080 50 8
161/MS
Pg 13.5
nickel-plated
600
50
2.584
2080 52 4
161/MS
Pg16
nickel-plated
500
25
3.013
2080 54 0
161/MS
Pg21
nickel-plated
350
25
5.154
2080 56 7
161/MS
Pg 29
nickel-plated
150
10
8.963
2080 58 3
161/MS
Pg36
nickel-plated
150
10
16.238
2080 60 5
Nom. size
Sealing range D
SS
E ca
D1
L
L1
L2
L3
G
Type 161MS
mm
mm
mm
max
mm
mm
mm
mm
mm
Pg 11
7.5-11.5
18
20
20
17
6
11
3
Pg 13.5
7.5-13.5
20
22.2
22
18
6.5
12.5
3
Pg 16
7.5-15.5
22
24.4
24
19
6.5
13.5
3
Pg 21
10 -20.5
28
31.2
30
22
7
15
3.5
Pg 29
18 -29
37
41
39
24
8
16.5
4
Pg 36
24 -37
47
50.5
50
29
9
19.5
4.5
With cutting ring
•Prices to DEL quotation; see Notes on Materials
Accessories available:
Thread entry seals
170 (Flat)
171 (O-ring)
see page 76 see page 77
161/MS: cable gland with round intermediate socket, Form C 5 to
DIN 46320
With Pg connecting thread to DIN 40430
Compression rings of steel, electro-galvanised and yellow-chromated
seal of NR/SBR
Degree of protection: with seal IP65, without IP54 With cutting ring
o o
<M <M
o
>!
m
C5
CO
m
>
Brass, nickel-plated
Ms
63
Please always state the ordering number when ordering.
