OBO
BETTERMANN
E
Type
Thread
Colour
Carton
Pack
Weight
Ord. no.
qty
qty
kg/100
Ms
160/MS
Pg 7
nickel-plated
1600
50
0.767
2080 07 9
160/MS
Pg 9
nickel-plated
1500
50
1.274
2080 09 5
160/MS
Pg 11
nickel-plated
600
25
1.818
2080117
160/MS
Pg 13.5
nickel-plated
600
50
2.244
208013 3
160/MS
Pgi6
nickel-plated
450
25
2.852
208016 8
160/MS
Pg21
nickel-plated
250
25
4.320
2080 21 4
160/MS
Pg29
nickel-plated
200
10
7.610
2080 28 1
160/MS
Pg36
nickel-plated
120
10
14.400
2080 36 2
160/MS
Pg42
nickel-plated
45
5
20.100
2080 42 7
160/MS
Pg48
nickel-plated
45
5
28.650
2080 48 6
Nom.
Sealing range D
SS
E
D1
L
L1
L2
L3
size
Type 160/MS
mm
ca
mm
max.
mm
mm
mm
G
mm
mm
mm
Pg 7
5- 7
13
14.3
14
15
5
10
2.5
Pg 9
6- 8
15
16.6
17
16
6
10.5
2.5
Pg 11
8-10
18
20
20
17
6
11
3
Pg 13.5
8-10
20
22.2
22
18
6.5
12.5
3
Pg 16
8-10
22
24.4
24
19
6.5
13.5
3
Pg 21
17-19
28
31.2
30
22
7
15
3.5
Pg 29
24-26
37
41
39
24
8
16.5
4
Pg 36
31-33
47
50.5
50
29
9
19.5
4.5
Pg 42
37-39
54
59
57
33
10
22
6
Pg 48
43-45
60
65
64
34
10
23
6
•Prices to DEL quotation; see Notes on Materials
Accessories available:
Thread entry seals
170 (Flat)
171 (o-ring)
see page 76 see page 77
160/MS: cable gland with round intermediate socket, Form C 5 to DIN 46320
With Pg connecting thread to DIN 40430
Compression rings of steel, electro-galvanised and yellow-chromated industrial seal of NR/SBR
Degree of protection: with seal IP65, without IP54 With single gasket, with small nominal diameter
Ms Brass, nickel-plated
D
L2
4
1
zr
D1
Type
Thread
Colour
Carton
Pack
Weight
Ord. no.
qty
qty
kg/100
Ms
160/MS M
M12
nickel-plated
800
50
1.058
2079 80 1
160/MS M
M16
nickel-plated
750
50
1.814
2079 82 8
160/MS M
M20
nickel-plated
600
50
2.526
2079 83 6
160/MS M
M25
nickel-plated
350
25
3.388
2079 84 4
160/MS M
M32
nickel-plated
400
25
5.004
2079 85 2
160/MS M
M40
nickel-plated
100
10
8.720
2079 86 0
160/MS M
M50
nickel-plated
60
10
15.800
2079 87 9
160/MS M
M63
nickel-plated
50
5
21.600
2079 88 7
Nom. size
Sealing range D
D1
L1
L2
G
Type 160/MS M
mm
mm
mm
mm
M12
5- 7
14
7
10
M16
6- 8
17
7
10.5
M20
8-10
22
7
12.5
M25
8-10
26
8
13.5
M32
17-19
34
8.5
15
M40
24-26
41
8.5
16.5
M50
31-33
54
9.5
19.5
M63
37-39
64
10.5
16.5
•Prices to DEL quotation; see Notes on Materials
160/MS M: cable gland with round intermediate socket, Form C 5 to
DIN 46320
With metric connecting thread to DIN EN 60423 or ISO 68 Compression rings of steel, electro-galvanised and yellow-chromated
seal of NR/SBR
Degree of protection: with seal IP65, without IP54 With single gasket, with small nominal diameter
Ms Brass, nickel-plated
Accessories available:
Thread entry seals 170M (Flat) see page 76
171M (o-ring) see page 77
62
Please always state the ordering number when ordering.
