OBO

BETTERMANN

Brass cable glands

D1/D2


Type	Thread	Colour	Pack	Weight	Ord. no.
			qty	kg/100	Ms

V-TEC LMS	Pg 7	nickel-plated	50	1.130	2085 72 0
V-TEC LMS	Pg 9	nickel-plated	50	1.740	2085 73 9
V-TEC LMS	Pg 11	nickel-plated	50	2.550	2085 74 7
V-TEC LMS	Pg 13.5	nickel-plated	50	3.030	2085 75 5
V-TEC LMS	Pg 16	nickel-plated	50	3.660	2085 76 3
V-TEC LMS	Pg 21	nickel-plated	25	6.580	2085 77 1
V-TEC LMS	Pg 29	nickel-plated	20	13.660	2085 79 8
V-TEC LMS	Pg 36	nickel-plated	10	22.700	2085 80 1
V-TEC LMS	Pg 42	nickel-plated	5	31.000	2085 82 8
V-TEC LMS	Pg 48	nickel-plated	5	37.900	2085 83 6


Nom.	Sealing	Strain relief and	Hexagon		Lmax.	L1	L2	L3
size	range	twist protection	SS	E	ca	V-TEC	mm	mm
G	D1	D2	mm	mm	mm	LMS
	mm	mm				mm
Pg 7	2.5- 6.5	3 - 6.5	14	15.5	20	10	3	12
Pg 9	2.5- 8	3.5- 8	17	18.9	22	10	3	14
Pg 11	3.5-10	4.5-10	20	22.2	24	10	3	15
Pg 13.5	5 -12	6 -12	22	24.4	25	10	3.5	16
Pg 16	7 -14	7 -14	24	26.7	27	10	4	17
Pg 21	9 -18	12 -18	30	33.5	33	12	4.5	20
Pg 29	14 -25	17 -25	40	43.5	39	12	5	23.5
Pg 36	18 -32	20 -32	50	54	49	15	5.5	29
Pg 42	24 -38	26 -38	57	61	52	15	6	31
Pg 48	30 -44	30 -44	64	69	52.5	15	6.5	31

With long connecting thread

•Prices to DEL quotation; see Notes on Materials

V-TEC LMS: cap-nut cable gland with wide sealing range and with strain relief and twist protection for high sealing demands, with long Pg connecting thread to DIN 40430 for thicker walls in combination with locknut Terminal insert of polyamide, gasket of chloroprene/nitrile rubber O-ring pre-fitted to the connecting thread Protection IP 68 at 5 bar 1 h. Tested to VDE 0619

Ms Brass, nickel-plated

L L


Nom.	can be used for cable	Hexagon		Lmax	L1	L2	L3
size	diameter of	SS	E	. ca	V-TEC	mm	mm
G	mm	mm	mm	mm	LMS mm
Pg 7	3.5- 6.5	14	15.5	20	10	3	12
Pg 9	5- 8	17	18.9	22	10	3	14
Pg 11	4.5-10	20	22.2	24	10	3	15
Pg 13.5	6.5-12	22	24.4	25	10	3.5	16
Pg 16	7 -14	24	26.7	27	10	4	17
Pg 21	12 -18	30	33.5	33	12	4.5	20
Pg 29	17 -25	40	43.5	39	12	5	23.5
Pg 36	20 -32	50	54	49	15	5.5	29
Pg 42	24 -38	57	61	52	15	6	31
Pg 48	30 -44	64	69	52.5	15	6.5	31


Type	Thread	Colour	Pack	Weight	Ord. no.
			qty	kg/100	Ms

V-TEC EX LMS	Pg 7	nickel-plated	50	1.130	2086 64 6
V-TEC EX LMS	Pg 9	nickel-plated	50	1.740	2086 65 4
V-TEC EX LMS	Pg h	nickel-plated	50	2.550	2086 66 2
V-TEC EX LMS	Pg 13.5	nickel-plated	50	3.030	2086 67 0
V-TEC EX LMS	Pg16	nickel-plated	50	3.660	2086 68 9
V-TEC EX LMS	Pg21	nickel-plated	25	6.580	2086 69 7
V-TEC EX LMS	Pg29	nickel-plated	20	13.660	2086 70 0
V-TEC EX LMS	Pg36	nickel-plated	10	22.700	2086 71 9
V-TEC EX LMS	Pg42	nickel-plated	5	31.000	2086 72 7
V-TEC EX LMS	Pg48	nickel-plated	5	37.900	2086 73 5

V-TEC EX LMS: cable gland with EC design type approval certificate for

devices and protection systems for use in accordance with the regulations in

explosion-hazard area - Directive 94/9/EC

EC design type approval certificate number:

PTB 99 ATEX 3111X

With long connecting thread

•Prices to DEL quotation; see Notes on Materials

cap-nut cable gland with wide sealing range and with strain relief and twist protection for high sealing demands, with long Pg connecting thread to DIN 40430 for thicker walls in combination with locknut Terminal insert of polyamide, gasket of chloroprene/nitrile rubber O-ring pre-fitted to the connecting thread Protection IP 68 at 5 bar 1 h. Tested to VDE 0619

Ms Brass, nickel-plated

Please always state the ordering number when ordering.
