Brass cable glands


Type	Thread	Colour	Pack	Weight	Ord. no.
			qty	kg/100	Ms

V-TEC MS	Pg 7	nickel-plated	50	1.000	2085 60 7
V-TEC MS	Pg 9	nickel-plated	50	1.600	2085 61 5
V-TEC MS	Pg 11	nickel-plated	50	2.300	2085 62 3
V-TEC MS	Pg 13.5	nickel-plated	50	2.800	2085 63 1
V-TEC MS	Pg 16	nickel-plated	25	3.400	2085 65 8
V-TEC MS	Pg21	nickel-plated	25	6.000	2085 66 6
V-TEC MS	Pg29	nickel-plated	20	13.000	2085 67 4
V-TEC MS	Pg36	nickel-plated	10	21.400	2085 68 2
V-TEC MS	Pg42	nickel-plated	5	29.200	2085 69 0
V-TEC MS	Pg48	nickel-plated	5	36.600	2085 70 4


Nom.	Sealing	Strain rel. and	Hexagon		L	L1	L2	L3
size	range	twist prot.	SS	E	max.	V-TEC	mm	mm
G	D1	D2	mm	mm	ca	mm
	mm	mm			mm
Pg 7	2.5- 6.5	3 - 6.5	14	15.5	20	5	3	12
Pg 9	2.5- 8	3.5- 8	17	18.9	22	6	3	14
Pg 11	3.5-10	4.5-10	20	22.2	24	6	3	15
Pg 13.5	5 -12	6 -12	22	24.4	25	6.5	3.5	16
Pg 16	7 -14	7 -14	24	26.7	27	6.5	4	17
Pg 21	9 -18	12 -18	30	33.5	33	7	4.5	20
Pg 29	14 -25	17 -25	40	43.5	39	8	5	23.5
Pg 36	18 -32	20 -32	50	54	49	9	5.5	29
Pg 42	24 -38	26 -38	57	61	52	10	6	31
Pg 48	30 -44	30 -44	64	69	52.5	10	6.5	31

•Prices to DEL quotation; see Notes on Materials

V-TEC MS: cap-nut cable gland with wide sealing range and with strain relief and twist protection for high sealing demands, with Pg connecting thread to DIN 40430. Terminal insert of polyamide, gasket of chloroprene/ni-trile rubber, with pre-fitted O-ring on the connecting thread Protection IP 68 at 5 bar, tested to VDE 0619 Connecting thread "normal" with reference to DIN 46320

Ms Brass, nickel-plated



	0	LU


Type	Thread	Colour	Pack	Weight	Ord. no.
			qty	kg/100	Ms

V-TEC EX MS	Pg 7	nickel-plated	50	1.130	2086 50 6
V-TEC EX MS	Pg 9	nickel-plated	50	1.740	2086 51 4
V-TEC EX MS	Pg 11	nickel-plated	50	2.550	2086 52 2
V-TEC EX MS	Pg 13.5	nickel-plated	50	3.030	2086 53 0
V-TEC EX MS	Pg16	nickel-plated	25	3.660	2086 54 9
V-TEC EX MS	Pg21	nickel-plated	25	6.580	2086 55 7
V-TEC EX MS	Pg 29	nickel-plated	20	13.660	2086 56 5
V-TEC EX MS	Pg 36	nickel-plated	10	22.700	2086 57 3
V-TEC EX MS	Pg 42	nickel-plated	5	31.000	2086 58 1
V-TEC EX MS	Pg 48	nickel-plated	5	37.900	2086 60 3


Nom.	can be used for ca-	Hexagon		Lmax	L1	L2	L3
size	ble diameter of	SS	E	. ca	mm	mm	mm
G	mm	mm	mm	mm
Pg 7	3.5- 6.5	14	15.5	20	5	3	12
Pg 9	5- 8	17	18.9	22	6	3	14
Pg 11	4.5-10	20	22.2	24	6	3	15
Pg 13.5	6.5-12	22	24.4	25	6, 5	3.5	16
Pg 16	7 -14	24	26.7	27	6, 5	4	17
Pg 21	12 -18	30	33.5	33	7	4.5	20
Pg 29	17 -25	40	43.5	39	8	5	23.5
Pg 36	20 -32	50	54	49	9	5.5	29
Pg 42	24 -38	57	61	52	10	6	31
Pg 48	30 -44	64	69	52.5	10	6.5	31

•Prices to DEL quotation; see Notes on Materials

V-TEC EX MS: cable gland with EC design type approval certificate for

devices and protection systems for use in accordance with the regulations in

explosion-hazard area - Directive 94/9/EC

EC design type approval certificate number:

PTB 99 ATEX 3111X

cap-nut cable gland with wide sealing range and with strain relief and twist protection for high sealing demands, with long Pg connecting thread to DIN 40430 for thicker walls in combination with locknut Terminal insert of polyamide, gasket of chloroprene/nitrile rubber O-ring pre-fitted to the connecting thread Protection IP 68 at 5 bar 1 h. Tested to VDE 0619

o o >

■J)

Brass, nickel-plated

Please always state the ordering number when ordering.
