OBO

BETTERMANN

End grommets for steel conduit



	11


Type	Nom.	Colour	Carton	Pack	Weight	Ord. no.
	size		qty	qty	kg/100	PE

129	Pg 7	1. grey	1000	100	0.145	2044 07 2
129	Pg 9	1. grey	1000	100	0.235	2044 09 9
129	Pg 11	1. grey	1000	100	0.276	204411 0
129	Pg 13.5	1. grey	1200	100	0.326	204413 7
129	Pg16	1. grey	1200	100	0.400	204416 1
129	Pg21	1. grey	600	50	0.614	2044 21 8
129	Pg29	1. grey	600	50	1.070	2044 29 3
129	Pg36	1. grey	600	50	1.444	2044 36 6
129	Pg42	1. grey	600	25	2.176	2044 42 0
129	Pg48	1. grey	600	25	2.808	2044 47 1


Nom. size	For con-	D1	D2	L1	L2
	duit	mm	mm	mm	mm
	0 mm
Pg 7	12.5	15.8	10	17	3.5
Pg 9	15.2	18.3	12	20	4
Pg 11	18.6	21.7	15	22	4
Pg 13.5	20.4	23.5	16	24	4
Pg 16	22.5	25.6	18	26	4
Pg 21	28.3	31.6	24	30	4
Pg 29	37	40.3	32.5	38	4
Pg 36	47	50.8	40	44	4
Pg 42	54	58.2	46	50	4
Pg 48	59.3	63.9	50	56	4


Type	Nom.	Colour	Carton	Pack	Weight	Ord. no.
	size		qty	qty	kg/100	PE

129	Pg 7	black	1000	100	0.145	2044 57 9
129	Pg 9	black	1000	100	0.235	2044 59 5
129	Pg 11	black	1000	100	0.276	2044 61 7
129	Pg 13.5	black	1200	100	0.326	2044 63 3
129	Pg16	black	1200	100	0.400	2044 66 8
129	Pg21	black	600	50	0.614	2044 71 4
129	Pg 29	black	600	50	1.070	2044 78 1
129	Pg36	black	600	50	1.444	2044 86 2
129	Pg 42	black	600	25	2.176	2044 92 7
129	Pg 48	black	600	25	2.808	2044 98 6

129: cable protection grommet to be fitted to steel conduit to DIN 49020 and medium- and heavy-duty conduits of insulating material to DIN 49016

PE Polyethylene, light grey (RAL 7035), black


129 M	M12	l. grey	1000	100	0.145	2047 80 2
129 M	M16	l. grey	1000	100	0.235	2047 81 0
129 M	M20	l. grey	1200	100	0.326	2047 82 9
129 M	M25	l. grey	600	50	0.614	2047 83 7
129 M	M32	l. grey	600	50	1.070	2047 85 3
129 M	M40	l. grey	600	50	1.444	2047 86 1
129 M	M50	l. grey	600	25	2.176	2047 88 8
129 M	M63	l. grey	600	25	2.808	2047 89 6


Nom. size	For con-	D1	D2	L1	L2
	duit	mm	mm	mm	mm
	0 mm
M12	12	15.4	9.5	15	2
M16	16	19.4	12.5	18	2
M20	20	23.4	16	22.5	2.5
M25	25	28.4	21	27.5	2.5
M32	32	35.4	27.5	34	3
M40	40	43.4	35	41	3
M50	50	53.4	44.5	48	3
M63	63	66.4	55	59	4


Type	Nom.	Colour	Carton	Pack	Weight	Ord. no.
	size		qty	qty	kg/100	PE

129 M	M12	black	1000	100	0.145	2047 92 6
129 M	M16	black	1000	100	0.235	2047 93 4
129 M	M20	black	1200	100	0.326	2047 94 2
129 M	M25	black	600	50	0.614	2047 95 0
129 M	M32	black	600	50	1.070	2047 96 9
129 M	M40	black	600	50	1.444	2047 97 7
129 M	M50	black	600	25	2.176	2047 98 5
129 M	M63	black	600	25	2.808	2047 99 3

129 M...: cable protection grommet to be fitted to electrical installation conduit to DIN EN 60423 or IEC 423 and other pipes/conduit with the same outside diameters

PE Polyethylene, light grey (RAL 7035), black

Please always state the ordering number when ordering.
