OBO
BETTERNIANN
Threaded nipples
Type
Connec-
Carton
Pack
Weight
Ord. no.
ting/
qty
qty
kg/100
PE
internal
thread
90
Pg 9
2700
100
0.192
2032 09 0
90
Pg 11
2700
100
0.200
2032112
90
Pg 13.5
1800
100
0.268
203213 9
90
Pg 16
1800
100
0.325
203216 3
90
Pg 21
500
50
0.513
2032 20 1
90
Pg 29
250
25
0.694
2032 29 5
90
Pg 36
100
10
0.875
2032 36 8
Nom. size
For cable
D
SS
E
L1
L2
G
0 mm
mm
mm
mm
mm
mm
Pg 9
5 - 9
4
17
19
9.5
6
Pg 11
6 - 10
5
19
21
9.5
6
Pg 13.5
8 - 13
7
22
24
9.5
6
Pg 16
8 - 13
7
24
26
9.5
6
Pg 21
10 - 16
9
30
33
11.5
6
Pg 29
16 - 23
15
37
40
11.5
6
Pg 36
24 -29
22
-
56
19
11
With opening of diameter D
Type
Connec-
Carton
Pack
Weight
Ord. no.
ting/
qty
qty
kg/100
PE
internal
thread
90
Pg 9
2700
100
0.192
2032 50 3
90
Pg 11
2700
100
0.200
2032 51 1
90
Pg 13.5
1800
100
0.268
2032 53 8
90
Pg 16
1800
100
0.325
2032 54 6
90
Pg 21
500
50
0.513
2032 55 4
90
Pg 29
250
25
0.694
2032 56 2
90
Pg 36
100
10
0.875
2032 57 0
90: Choke seal to be screwed into Pg thread to DIN 40430 With self sealing cone at the thread end Protection achievable with careful assembly IP 54
2 Patterns:
a) With open cable entry
b) With push-through membrane. Here the opening D is pre-embossed, but initially closed.
With push-through membrane
PE Polyethylene, light grey (RAL 7035)
Type
Thread
Carton
Pack
Weight
Ord. no.
qty
qty
kg/100
PE
90 M
M12 x 1.5
2700
100
0.170
2032 00 7
90 M
M16 x 1.5
2700
100
0.192
2032 01 1
90 M
M20 x 1.5
1800
100
0.268
2032 01 5
90 M
M25 x 1.5
500
50
0.513
2032 01 9
90 M
M32 x 1.5
250
25
0.694
2032 02 3
90 M
M40 x 1.5
100
10
0.875
2032 03 1
Nom. size
For cable
SS
D
G
0 mm
mm
mm
M12 x 1.5
3- 6
13
3, 5
M16 x 1.5
5- 9
16
5
M20 x 1.5
8-13
21
7
M25 x 1.5
10-16
30
8.5
M32 x 1.5
16-23
34
13
M40 x 1.5
24-29
44
16
With opening of diameter D
Type
Thread
Carton
Pack
Weight
Ord. no.
qty
qty
kg/100
PE
90 M
M12 x 1.5
2700
100
0.170
2032 37 8
90 M
M16 x 1.5
2700
100
0.192
2032 38 0
90 M
M20 x 1.5
1800
100
0.268
2032 38 2
90 M
M25 x 1.5
500
50
0.513
2032 38 4
90 M
M32 x 1.5
250
25
0.694
2032 38 6
90 M
M40 x 1.5
100
10
0.875
2032 38 8
90 M...: Choke seal to be screwed into metric thread to IEC 423 With self sealing cone at the thread end Protection achievable with careful assembly IP 54
2 Patterns:
a) With open cable entry
b) With push-through membrane. Here the opening D is pre-embossed, but initially closed.
With push-through membrane
PE Polyethylene, light grey (RAL 7035)
58
Please always state the ordering number when ordering.
