OBO
BETTERMANN
Threaded bushes
Nom. size
D
L1
L2
SS
E
G
mm
mm
mm
mm
mm
Pg 7
7
8.5
5
13
14.7
Pg 9
10.2
9
5
16
18
Pg 11
11.3
10
5
19
21.5
Pg 13.5
13.4
10.5
5
21
23.8
Pg 16
15.8
12
6
23
26
Pg 21
21.2
17
7
30
34
Pg 29
30
18
8
40
45
Pg 36
38.2
17
8
50
56.5
Pg 42
44.5
18.5
9
55
62
Pg 48
50
18.5
9
60
68
halogen-free
chlorine fluorine bromine
Type
Thread
Colour
Pack
Weight
Ord. no.
qty
kg/100
PA
107/EVDE
Pg 7
1. grey
100
0.158
2025 50 7
107/EVDE
Pg 9
1. grey
100
0.180
2025 51 5
107/EVDE
Pg 11
1. grey
100
0.270
2025 53 1
107/EVDE
Pg 13.5
1. grey
100
0.340
2025 56 6
107/EVDE
Pg16
1. grey
100
0.450
2025 58 2
107/EVDE
Pg21
1. grey
50
0.780
2025 60 4
107/EVDE
Pg29
1. grey
25
1.280
2025 62 0
107/E VDE
Pg36
1. grey
25
2.830
2025 64 7
107/E VDE
Pg42
1. grey
10
5.010
2025 66 3
107/E VDE
Pg48
1. grey
10
6.250
2025 69 8
107/E VDE: Threaded bush Part 1 to DIN 46320, glassfibre-reinforced PA Polyamide, light grey (RAL 7035)
D
halogen-free
chlorine fluorine bromine
Nom. size
Clamping
L1
L2
SS
E
G
range D
mm
mm
mm
mm
mm
Pg 9
3.5-11.3
8.5
14.5
19
21
Pg 11
4 -13.3
9
16
21
23
Pg 13.5
4.1-14.3
10
17
23
25
Pg 16
5 -16.2
10
19
25
27
Pg 21
5.9-21.2
12.5
23.5
32
35
Pg 29
7.1-29
16
30
42
45
CM
_i
Type
Thread
Colour
Pack
Weight
Ord. no.
qty
kg/100
PA
107/Z
Pg 9
1. grey
100
0.400
2023 09 1
107/Z
Pg 11
1. grey
100
0.600
2023 11 3
107/Z
Pg 13.5
1. grey
100
0.680
202312 1
107/Z
Pg 16
1. grey
50
0.900
202316 4
107/Z
Pg 21
1. grey
25
1.800
2023 21 0
107/Z
Pg 29
1. grey
25
3.000
2023 29 6
_i
G
(0)
SS
E
With strain relief
107/Z: Threaded bush with crossbar strain relief Screws, steel, electro-galvanised Pg thread to DIN 40430
Polyamide, light grey (RAL 7035)
PA
Reducers
L2 L1
Type
Connecting/
Colour
Pack
Weight
Ord. no.
internal
qty
kg/100
PA
thread
107/R
Pg 11 /7
1. grey
50
0.400
2030 70 5
107/R
Pg 13.5/ 9
1. grey
50
0.450
2030 71 3
107/R
Pg 16 /9
1. grey
50
0.600
2030 74 8
107/R
Pg 16 /11
1. grey
50
0.480
2030 75 6
107/R
Pg 21 /11
1. grey
50
0.910
2030 76 4
107/R
Pg 21 /13.5
1. grey
50
0.800
2030 77 2
107/R
Pg 21 /16
1. grey
50
0.650
2030 78 0
107/R
Pg29 /16
1. grey
50
1.460
2030 79 9
107/R
Pg29 /21
1. grey
25
1.500
2030 80 2
107/R
Pg36 /21
1. grey
25
2.350
2030 82 9
107/R
Pg36 /29
1. grey
25
2.200
2030 81 0
107/R
Pg42 /29
1. grey
25
2.350
2030 83 7
Nom. size
G1
G2
L1
L2
L3
D
SS
E
mm
mm
mm
mm
mm
mm
mm
mm
Pg 11 / 7
Pg 11
Pg 7
8
6
9.5
7.5
22
24
Pg 13.5/ 9
Pg 13.5
Pg 9
8.5
6
9.5
9.5
24
26
Pg 16 / 9
Pg 16
Pg 9
9.5
6
11.5
9.5
27
29
Pg 16 /11
Pg 16
Pg 11
9.5
6
11
11.5
27
29
Pg 21 /11
Pg 21
Pg 11
10.5
5
11
11.5
32
35.5
Pg 21 /13.5
Pg 21
Pg 13.5
10.5
5
11
13.5
32
35.5
Pg 21 /16
Pg 21
Pg 16
10.5
5
11
16.5
32
35.5
Pg 29 /16
Pg 29
Pg 16
12
6
12.5
16.5
40
43
Pg 29 /21
Pg 29
Pg 21
12.5
6
13.5
21.5
39
43
Pg 36 /21
Pg 36
Pg 21
13
6
13.5
21
50
54
Pg 36 /29
Pg 36
Pg 29
18
6
18
28.5
50
54
Pg 42 /29
Pg 42
Pg 29
16
6
17
27.5
55
59
107/R: Reducer
Pg internal and external thread to DIN 40430
CM
o o
CM CM
o
CM
>!
m
C5
WD m >
PA Polyamide, light grey (RAL 7035)
55
Please always state the ordering number when ordering.
