OBO

BETTERNIANN

Screw plugs

D


	Type	Thread	Colour	Carton	Pack	Weight	Ord. no.
				qty	qty	kg/100	PS

	108	Pg 7	1. grey	2000	100	0.146	2033 07 0
	108	Pg 9	1. grey	2000	100	0.161	2033 09 7
	108	Pg h	1. grey	1800	100	0.178	2033119
	108	Pg 13.5	1. grey	1200	100	0.209	203313 5
	108	Pg16	1. grey	1000	100	0.235	203315 1
	108	Pg21	1. grey	1000	100	0.355	2033 21 6
	108	Pg29	1. grey	500	50	0.786	2033 29 1
	108	Pg36	1. grey	200	25	1.280	2033 36 4
	108	Pg42	1. grey	250	25	1.400	2033 42 9
	108	Pg48	1. grey	300	25	1.850	2033 48 8

108: Screw plug to DIN 46320, with Pg thread to DIN 40430


	Type	Thread	Colour	Carton	Pack	Weight	Ord. no.
				qty	qty	kg/100	PS

	108 m	M12X1.5	1. grey	3000	100	0.146	2033 00 3
	108 m	M16X1.5	1. grey	2000	100	0.161	2033 00 7
	108 m	M20X1.5	1. grey	1200	100	0.209	2033 01 1
	108 m	M25X1.5	1. grey	1000	100	0.355	2033 01 6
	108 m	M32X1.5	1. grey	500	50	0.786	2033 02 1
	108 m	M40X1.5	1. grey	200	25	1.280	2033 02 6
	108 m	M50X1.5	1. grey	250	25	1.400	2033 03 2
	108 m	M63X1.5	1. grey	300	25	1.850	2033 03 8


	Nom. size	D	L
	G	mm	mm
	M12 x 1.5	15	6
	M16 x 1.5	20	6
	M20 x 1.5	24	6
	M25 x 1.5	30	8
	M32 x 1.5	37	8
	M40 x 1.5	46	8
	M50 x 1.5	56	10
	M63 x 1.5	70	12

108 M...: Screw plug to DIN 46320, with metric thread to IEC 423

PS Polystyrene, light grey (RAL 7035)

Threaded bushes

halogen-free

chlorine fluorine bromine


	Type	Thread	Colour	Pack	Weight	Ord. no.		Nom. size	D	L1	L2	SS	E
				qty	kg/100	PS		G	mm	mm	mm	mm	mm
								Pg 7	7	8.5	5	13	14.7
								Pg 9	10.2	9	5	16	18
	107/E	Pg 7	I. grey	100	0.115	2025 07 8		Pg 11	11.3	10	5	19	21.5
	107/E	Pg 9	1. grey	100	0.170	2025 09 4		Pg 13.5	13.4	10.5	5	21	23.8
	107/E	Pg 11	I. grey	100	0.180	2025 11 6		Pg 16	15.8	12	6	23	26
	107/E	Pg 13.5	I. grey	100	0.325	202513 2		Pg 21	21.2	17	7	30	34
	107/E	Pg 16	I. grey	100	0.404	202516 7		Pg 29	30	18	8	40	45
	107/E	Pg 21	I. grey	50	0.696	2025 21 3		Pg 36	38.2	17	8	50	56.5
	107/E	Pg 29	I. grey	25	1.296	2025 29 9		Pg 42	44.5	18.5	9	55	62
	107/E	Pg 36	I. grey	25	2.508	2025 36 1		Pg 48	50	18.5	9	60	68
	107/E	Pg 42	I. grey	10	4.540	2025 42 6
	107/E	Pg 48	I. grey	10	5.580	2025 48 5


	Type	Thread	Colour	Pack	Weight	Ord. no.
				qty	kg/100	PS

	107/E	Pg 9	black	100	0.170	2026 09 0
	107/E	Pg 11	black	100	0.180	2026112
	107/E	Pg 13.5	black	100	0.325	202613 9
	107/E	Pg 16	black	100	0.404	202616 3

107/E: Threaded bush (Part 1) to DIN 46320, Pg thread to DIN 40430

PS Polystyrene, light grey (RAL 7035)

O O

o >

■Si

54

Please always state the ordering number when ordering.
