OBO

BETTERMANN

Locknuts

_J

halogen-free

chlorine fluorine bromine


	Type	Thread	Colour	Car-	Pac	Weight	Ord. no.
				ton	k	kg/100	PS
				qty	qty

	116/M	M12X1.5	1. grey	2000	100	0.100	2049 50 3
	116/M	M16X1.5	1. grey	2000	100	0.160	2049 51 1
	116/M	M20X1.5	1. grey	1000	100	0.250	2049 53 8
	116/M	M25X1.5	1. grey	1000	100	0.350	2049 54 6
	116/M	M32X1.5	1. grey	500	50	0.610	2049 55 4
	116/M	M40X1.5	1. grey	250	25	1.683	2049 56 2
	116/M	M50X1.5	1. grey	250	25	1.756	2049 57 0
	116/M	M63X1.5	1. grey	250	25	1.830	2049 58 9

UJ

G

SS


	Nom. size	SS	E	L
	G	mm	mm	mm
	M12 x 1.5	17	19	5
	M16 x 1.5	22	25	5
	M20 x 1.5	26	29	6
	M25 x 1.5	32	36	6.5
	M32 x 1.5	41	46	7
	M40 x 1.5	50	56	7.5
	M50 x 1.5	60	68	8
	M63 x 1.5	75	83	8.5

With metric thread to IEC 423

116/M: Locknut to DIN 46319, with metric thread to IEC 423 PS Polystyrene, light grey (RAL 7035)

......I......


	Type	Thread	Colour	Car-	Pac	Weight	Ord. no.
				ton	k	kg/100	PA
				qty	qty

	116/M VDE	M12 X 1.5	silver-grey	2000	100	0.100	2048 75 2
	116/M VDE	M16X1.5	silver-grey	2000	100	0.160	2048 76 0
	116/M VDE	M20 X 1.5	silver-grey	1000	100	0.250	2048 77 9
	116/M VDE	M25X1.5	silver-grey	1000	100	0.350	2048 78 7
	116/M VDE	M32X1.5	silver-grey	500	50	0.610	2048 79 5
	116/M VDE	M40 X 1.5	silver-grey	250	25	1.683	2048 80 9
	116/M VDE	M50 X 1.5	silver-grey	250	25	1.756	2048 81 7
	116/M VDE	M63X1.5	silver-grey	250	25	1.830	2048 82 5

SS


	Type	Thread	Colour	Car-	Pac	Weight	Ord. no.
				ton	k	kg/100	PA
				qty	qty

	116/M VDE	M12 X 1.5	l. grey	2000	100	0.100	2048 90 6
	116/M VDE	M16X1.5	l. grey	2000	100	0.160	2048 91 4
	116/M VDE	M20 X 1.5	l. grey	1000	100	0.250	2048 92 2
	116/M VDE	M25X1.5	l. grey	1000	100	0.350	2048 93 0
	116/M VDE	M32X1.5	l. grey	500	50	0.610	2048 94 9
	116/M VDE	M40 X 1.5	l. grey	250	25	1.683	2048 95 7
	116/M VDE	M50 X 1.5	l. grey	250	25	1.756	2048 96 5
	116/M VDE	M63X1.5	l. grey	250	25	1.830	2048 97 3


	Nom. size	SS	E	L
	G	mm	mm	mm
	M12 x 1.5	17	19	5
	M16 x 1.5	22	25	5
	M20 x 1.5	26	29	6
	M25 x 1.5	32	36	6.5
	M32 x 1.5	41	46	7
	M40 x 1.5	50	56	7.5
	M50 x 1.5	60	68	8
	M63 x 1.5	75	83	8.5


	Type	Thread	Colour	Car-	Pac	Weight	Ord. no.
				ton	k	kg/100	PA
				qty	qty

	116/M VDE	M12 X 1.5	black	2000	100	0.100	2049 06 6
	116/M VDE	M16X1.5	black	2000	100	0.160	2049 07 4
	116/M VDE	M20 X 1.5	black	1000	100	0.250	2049 08 2
	116/M VDE	M25X1.5	black	1000	100	0.350	2049 09 0
	116/M VDE	M32X1.5	black	500	50	0.610	204910 4
	116/M VDE	M40 X 1.5	black	250	25	1.683	2049 11 2
	116/M VDE	M50 X 1.5	black	250	25	1.756	2049 12 0
	116/M VDE	M63X1.5	black	250	25	1.830	2049 13 9

116/M VDE: Locknut to DIN 46319, with metric thread to IEC 423 PA Polyamide

With metric thread to IEC 423

53

Please always state the ordering number when ordering.
