OBO

BETTERNIANN

Locknuts

halogen-free

chlorine fluorine bromine


	Type	Thread	Colour	Carton	Pack	Weight	Ord. no.
				qty	qty	kg/100	PS

	116	Pg 7	1. grey	4000	100	0.077	2043 07 6
	116	Pg 9	1. grey	3000	100	0.114	2043 09 2
	116	Pg 11	1. grey	3000	100	0.151	204311 4
	116	Pg 13.5	1. grey	2700	100	0.210	204313 0
	116	Pg 16	1. grey	2700	100	0.267	204316 5
	116	Pg 21	1. grey	1200	100	0.343	2043 21 1
	116	Pg 29	1. grey	500	50	0.902	2043 29 7
	116	Pg 36	1. grey	250	25	1.380	2043 35 1
	116	Pg 42	1. grey	250	25	1.440	2043 42 4
	116	Pg 48	1. grey	250	25	1.500	2043 48 3

LU

G

SS


	Nom. size	SS	E	L
	G	mm	mm	mm
	Pg 7	19	21	5
	Pg 9	22	24	5
	Pg 11	24	26	5
	Pg 13.5	27	29	6
	Pg 16	30	33	6
	Pg 21	36	39	7
	Pg 29	46	50	7
	Pg 36	60	66	8
	Pg 42	65	73	8
	Pg 48	70	78	8


	Type	Thread	Colour	Carton	Pack	Weight	Ord. no.
				qty	qty	kg/100	PS

	116	Pg 7	black	4000	100	0.077	2043 57 2
	116	Pg 9	black	3000	100	0.114	2043 59 9
	116	Pg 11	black	3000	100	0.151	2043 61 0
	116	Pg 13.5	black	2700	100	0.210	2043 63 7
	116	Pg 16	black	2700	100	0.267	2043 66 1
	116	Pg 21	black	1200	100	0.343	2043 71 8
	116	Pg 29	black	500	50	0.902	2043 79 3
	116	Pg 36	black	250	25	1.380	2043 86 6
	116	Pg 42	black	250	25	1.440	2043 92 0
	116	Pg 48	black	250	25	1.500	2043 97 1

116: Locknut to DIN 46320, with Pg thread to DIN 40430 PS Polystyrene, light grey (RAL 7035)

_l

halogen-free

chlorine fluorine bromine

LU


	Type	Thread	Colour	Carton	Pack	Weight	Ord. no.
				qty	qty	kg/100	PA

	116 VDE	Pg 7	l. grey	2000	100	0.093	2048 07 8
	116 VDE	Pg 9	l. grey	3000	100	0.169	2048 09 4
	116VDE	Pg h	l. grey	3000	100	0.184	2048 11 6
	116VDE	Pg 13.5	l. grey	2400	100	0.256	2048 13 2
	116VDE	Pg16	l. grey	2400	100	0.325	204816 7
	116VDE	Pg21	l. grey	1600	100	0.509	2048 22 1
	116VDE	Pg29	l. grey	500	50	1.100	2048 29 9
	116VDE	Pg36	l. grey	250	25	1.683	2048 36 1
	116VDE	Pg42	l. grey	250	25	1.756	2048 42 6
	116VDE	Pg48	l. grey	250	25	1.830	2048 48 5

G

SS


	Nom. size	SS	E	L
	G	mm	mm	mm
	Pg 7	19	21	5
	Pg 9	22	24	5
	Pg 11	24	26	5
	Pg 13.5	27	29	6
	Pg 16	30	33	6
	Pg 21	36	39	7
	Pg 29	46	50	7
	Pg 36	60	66	8
	Pg 42	65	73	8
	Pg 48	70	78	8

o

O

o

> m

■Si

m >

52 Please always state the ordering number when ordering.
