OBO VARIOBOX

59 23.5 37.6
Type Colour Cartonqty Packqty Weightkg/100 Ord. no. PP 4545 5 5 18.300 10.600 2008556 2008106 110 VBX60: Protection with push-in seal IP 54; with cable glands IP 65Rated voltage 400 V With 4 captive lid screws4 fixing holes for screws Ø 5 mm inside the box (spacing: 60 mm)A cut-out tool is supplied with every VARIOBOX. Using the tool and a screwdriver, the entries can be cleanly cut-out. (Cut-out tool Pg 16/21 with slot for screwdriver bit on request) Nominal cross-section 4 - 6 mm Accessories available: Terminal stripsVBX/KL 60see page 29Push-in sealsED 16see page 26 Push-in sealsED 21see page 26Entry plugsVS 16see page 27Entry plugsVS 21see page 27Mounting plateVBX/MOsee page 17
2 7 entries Pg 16/Pg 21 Clear internal dimensions: 102 x 102 x 40.5Supplied with VBX 60: Supplied with VBX 60 empty: 3 push-in seals ED 213 push-in seals ED 21 1 entry plug VS 211 entry plug VS 211 cut-out tool Pg 211 cut-out tool Pg 211 terminal strip VBX/KL 60 PP Polypropylene, light grey (RAL 7035)

M

59 23.5 37.6
Type Colour Cartonqty Packqty Weightkg/100 Ord. no. PP 4545 5 5 18.300 10.600 20085642008114 110 Accessories available: Terminal stripsVBX/KL 60see page 29Push-in sealsEDVS 20see page 27Push-in sealsEDVS 25see page 27Mounting plateVBX/MOsee page 17 VBX60 M: Protection with push-in seal IP 54; with cable glands IP 65Rated voltage 400 V With 4 captive lid screws4 fixing holes for screws Ø 5 mm inside the box (spacing: 60 mm)Nominal cross-section 4 - 6 mm
2 7 entries M20/M25 Clear internal dimensions: 102 x 102 x 40.5Supplied with VBX 60 M: Supplied with VBX 60 M empty: 3 cable entries EDVS 253 cable entries EDVS 25 1 terminal strip VBX/KL 60 PP Polypropylene, light grey (RAL 7035)

16

Please always state the ordering number when ordering.
