OBO

BETTERMANN

Flat-cable glands

Pg 16

3 J SS27

Pg'16


	Type	Thread/for flat	Colour	Car-	Pack	Weight	Ord. no.
		cable width		ton	qty	kg/100	PE
		mm		qty

	106/FL	Pg 16/17 -19	1. grey	600	50	1.350	2012 75 8
	106/FL	Pg 21/27 -30	1. grey	200	25	2.630	2012 85 5
	106/FL	Pg 21/30 -33	1. grey	200	25	2.630	2012 78 2
	106/FL	Pg 21/19 -22	1. grey	250	25	2.630	2012 82 0
	106/FL	Pg 21/36 -39	1. grey	250	25	2.630	2012 80 4
	106/FL	Pg 21/26 -29	1. grey	200	25	2.630	2012 83 9
	106/FL	Pg 21/28.5-31.5	1. grey	250	25	2.630	2012 87 1
	106/FL	Pg 21/31 -35	1. grey	250	25	2.630	2012 84 7
	106/FL	Pg 21/37 -40	1. grey	250	25	2.680	2012 92 8
	106/FL	Pg 29/27 -30	1. grey	150	15	3.450	2012 68 5
	106/FL	Pg 29/30 -33	1. grey	150	15	3.450	2012 94 4
	106/FL	Pg 29/19 -22	1. grey	150	15	3.450	2012 67 7
	106/FL	Pg 29/36 -39	1. grey	180	15	3.450	2012 95 2
	106/FL	Pg 29/26 -29	1. grey	150	15	3.450	2012 76 6
	106/FL	Pg 29/28.5-31.5	1. grey	150	15	3.450	2012 96 0
	106/FL	Pg 29/31 -35	1. grey	150	15	3.450	2012 97 9
	106/FL	Pg 29/37 -40	1. grey	150	15	3.500	2012 77 4


	Thread	For flat cable
		Thickness mm	Width mm
	Pg 16	6- 8	17 -19
	Pg 21	4- 6	27 -30
	Pg 21	6- 8	30 -33
	Pg 21	7- 9	19 -22
	Pg 21	7- 9	36 -39
	Pg 21	8 -10	26 -29
	Pg 21	8.5-10.5	28.5-31.
	Pg 21	9 -12	31 -35
	Pg 21	11 -14	37 -40
	Pg 29	4- 6	27 -30
	Pg 29	6- 8	30 -33
	Pg 29	7- 9	19 -22
	Pg 29	7- 9	36 -39
	Pg 29	8 -10	26 -29
	Pg 29	8.5-10.5	28.5-31.
	Pg 29	9 -12	31 -35
	Pg 29	11 -14	37 -40

Pg 21

Pg 29

Pg 29

044

UH

56

106/FL: Flat-cable entry, choke-nipple design With Pg connecting thread to DIN 40430 Protection IP 31

With pre-fitted spigot seal 107/F

Polyethylene

PE

o

O

o >

ai

CD >

50

Please always state the ordering number when ordering.
