OBO
BETTERMANN
Conical cable glands
D3 D1
halogen-free
chlorine fluorine bromine
Type
Thread
Colour
Carton
Pack
Weight
Ord. no.
qty
qty
kg/100
PS
106
Pg 7
1. grey
900
50
0.396
2036 06 1
106
Pg 9
1. grey
500
50
0.562
2036 09 6
106
Pg 11
1. grey
500
50
0.798
2036118
106
Pg 13.5
1. grey
600
50
0.900
203613 4
106
Pg 16
1. grey
600
50
1.228
203616 9
106
Pg 21
1. grey
600
50
2.112
2036 21 5
106
Pg 29
1. grey
120
10
3.700
2036 29 0
106
Pg 36
1. grey
80
10
6.240
2036 36 3
106
Pg 42
1. grey
50
5
8.500
2036 42 8
106
Pg 48
1. grey
50
5
9.633
2036 48 7
Nom.
Sealing
D2
D3
D4
Spanner
L1
L2
L3
L4
L
size
range
mm
mm
mm
size
mm
mm
mm
mm
max.
G
D1 mm
SS1
SS2
ca mm
Pg 7
3.5- 6.5
16.5
7
7
15
13
8
13
5
8.5
23
Pg 9
4.5- 7
21.5
10.2
10.2
19
16
8
14
5
9
25
Pg 11
5.5-10
25
11.3
11.5
22
19
8
15
5
10
27
Pg 13.5
9 -13
27
13.4
13.5
24
21
9
16
5
10.8
28
Pg 16
10 -14
30
15.8
16.5
27
23
10
16.5
6
12
30
Pg 21
14 -18
37.5
21.2
21
33
30
11
19
7
17
38
Pg 29
18 -25
47.5
30
27.5
42
40
11
20.5
8
18
42
Pg 36
25 -33
58
38
34.5
53
50
12
24
8
17
43
Pg 42
30 -38
65
44.5
40.5
60
55
13
27
9
18.5
48
Pg 48
37 -44
70
50
45.5
65
60
14
27
9
18.5
48
Form A to DIN 46320
Accessories available:
Thread entry seals
107/F (Flat) 171 (O-rlng)
see page 75 see page 77
106: Standard cable gland, Form A to DIN 46320 with single industrial seal of NR/SBR, Pg connecting thread to DIN 40430 Degree of protection: with seal IP65, without IP54.
Note: cable glands of polystyrene should not be over-tightened because of the risk of stress cracking.
halogen-free
chlorine fluorine
Type
Thread
Colour
Pack
Weight
Ord. no.
qty
kg/100
PS
106 M
M12
1. grey
50
0.396
2035 31 6
106 M
M16
1. grey
50
0.562
2035 32 4
106 M
M20
1. grey
50
0.900
2035 33 2
106 M
M25
1. grey
50
2.112
2035 34 0
106 M
M32
1. grey
10
3.700
2035 35 9
106 M
M40
1. grey
10
6.240
2035 36 7
106 M
M50
1. grey
5
8.500
2035 37 5
106 M
M63
1. grey
5
9.633
2035 38 3
Nom.
Sealing
D2
D3
D4
Spanner
L1
L2
L3
L4
L
size
range
mm
mm
mm
size
mm
mm
mm
mm
max.
G
D1
mm
SS1
SS2
ca mm
M12
3.5- 6.5
16.5
7
7
15
13
8
13
5
8.5
23
M16
4.5- 7
21.5
10.2
10
19
16
8
14
5
9
25
M20
9 -13
25
11.3
13
22
19
8
15
5
10
27
M25
10 -14
27
13.4
16
24
21
9
16
5
10.8
28
M32
18 -25
30
15.8
26
27
23
10
16.5
6
12
30
M40
25 -33
37.5
21.2
33
33
30
11
19
7
17
38
M50
30 -38
47.5
30
40.5
42
40
11
20.5
8
18
42
M63
37 -44
58
38
45.5
53
50
12
24
8
17
43
Form A to DIN 46320
Accessories available:
Thread entry seals 107/FM (Flat) see page 84
171 (O-ring) see page 77
106 M...: Standard cable gland, Form A to DIN 46320 with single seal of NR/SBR
With metric connecting thread to IEC 423 Degree of protection: with seal IP65, without IP54.
Note: cable glands of polystyrene should not be over-tightened because of the risk of stress cracking.
o
O
o
> m
■Si ED >
44
Please always state the ordering number when ordering.
