OBO
BETTERMANN
Conical cable glands
D3 D1
halogen-free
chlorine fluorine bromine
Type
Thread
Colour
Carton
Pack
Weight
Ord. no.
qty
qty
kg/100
PS
106/B
Pg 9
1. grey
500
50
0.700
2036 08 8
106/B
Pg 11
1. grey
500
50
0.977
203612 6
106/B
Pg 13.5
1. grey
500
50
1.050
203614 2
106/B
Pg16
1. grey
500
50
1.585
203615 0
106/B
Pg21
1. grey
500
50
2.594
2036 22 3
106/B
Pg29
1. grey
100
10
5.483
2036 30 4
106/B
Pg36
1. grey
160
10
10.238
2036 37 1
106/B
Pg42
1. grey
50
5
18.513
2036 43 6
106/B
Pg48
1. grey
50
5
21.138
2036 49 5
Nom.
Sealing
D2
D3
D4
Spanner
L1
L2
L3
L4
Lmax
size
range
mm
mm
mm
size
mm
mm
mm
mm
ca
G
D1 mm
SS1
SS2
mm
Pg 9
5 -10
21.5
10.2
10.2
19
16
8
14
5
9
25
Pg 11
7.5-11.5
25
11.3
11.5
22
19
8
15
5
10
27
Pg 13.5
7.5-13
27
13.4
13.5
24
21
9
16
5
10.8
28
Pg 16
7.5-15
30
15.8
16.5
27
23
10
16.5
6
12
30
Pg 21
10 -20
37.5
21.2
21
33
30
11
19
7
17
38
Pg 29
18 -27
47.5
30
27.5
42
40
11
20.5
8
18
42
Pg 36
24 -34
58
38
34.5
53
50
12
24
8
17
43
Pg 42
30 -40
65
44.5
40.5
60
55
13
27
9
18.5
48
Pg 48
36 -45
70
50
45.5
65
60
14
27
9
18.5
48
With cutting ring
Accessories available:
Thread entry seals
107/F (Flat) 171 (O-ring)
see page 75 see page 77
106/B: cable gland Form A to DIN 46320 Pg connecting thread to DIN 40430
With cutting ring of NR/SBR, giving extended sealing range Degree of protection: with industrial seal IP65, without IP54.
Note: cable glands of polystyrene should not be over-tightened because of the risk of stress cracking.
Polystyrene
PS
D3
D1
SW2
halogen-free
chlorine fluorine bromine
Type
Colour
Pack
Weight
Ord. no.
qty
kg/100
qty
PS
106/B M16x1,5
light grey
50
0,562
2035 51 0
106/B M20x1,5
light grey
50
0,900
2035 51 2
106/B M25x1,5
light grey
50
2,112
2035 51 4
106/B M32x1,5
light grey
10
3,700
2035 51 6
106/B M40x1,5
light grey
10
6,240
2035 51 8
106/B M50x1,5
light grey
5
8,500
2035 52 0
106/B M63x1,5
light grey
5
9,633
2035 52 2
Nom.
Sealing
D2
D3
D4
Spanner
L1
L2
L3
L4
Lmax.
size
range
mm
mm
mm
size
mm
mm
mm
mm
ca.
G
D1 mm
SW1
SW2
mm
16
5 -10
21,5
10,2
10,2
19
16
8
14
5
9
25
20
7,5-13
27
13,4
13,5
24
21
9
16
5
10,8
28
25
7,5-15
30
15,8
16,5
27
23
10
16,5
6
12
30
32
18 -27
47,5
30
27,5
42
40
11
20,5
8
18
42
40
24 -34
58
38
34,5
53
50
12
24
8
17
43
50
30 -40
65
44,5
40,5
60
55
13
27
9
18,5
48
63
36 -45
70
50
45,5
65
60
14
27
9
18,5
48
With cutting ring
106/B M...: cable gland Form A to DIN 46320
With cutting ring of NR/SBR, giving extended sealing range
With metric connecting thread to IEC 423
Degree of protection: with seal IP65, without IP54.
Note: cable glands of polystyrene should not be over-tightened because of the risk of stress cracking.
Polystyrene
PS
CM
o o
<M <M
o
C\]
>!
m
C5
CO
m
>
43
Please always state the ordering number when ordering.
