OBO VARIOBOX

46 18 27.6
Type Colour Cartonqty Packqty Weightkg/100 Ord. no. PP 8080 5 5 10.2006.100 2008432 2008068 85 Accessories available: VBX 25: Protection with push-in seal IP 54; with cable glands IP 65Rated voltage 400 V With 4 captive lid screws4 fixing holes for screws Ø 5 mm inside the box (spacing: 45 mm)A cut-out tool is supplied with every VARIOBOX. Using the tool and a screwdriver, the entries can be cleanly cut-out. (Cut-out tool Pg 13.5)Nominal cross-section 2.5–4 mm Push-in sealsED 13see page 26Entry plugsVS 13see page 27Terminal stripsVBX/KL 25see page 28Mounting plateVBX/MOsee page 17
2 7 entries Pg 13.5 Clear internal dimensions: 78 x 78 x 30.5Supplied with VBX 25: Supplied with VBX 25 empty: 3 push-in seals ED 133 push-in seals ED 131 entry plug VS 131 entry plug VS 131 cut-out tool1 cut-out tool1 terminal strip VBX/KL 25 PP Polypropylene, light grey (RAL 7035)

M

46 18 27.6
Type Colour Cartonqty Packqty Weightkg/100 Ord. no. PP 8080 5 5 10.2006.100 2008440 2008076 85 Accessories available: Terminal stripsVBX/KL 25see page 28Cable entriesEDVS 20see page 27Mounting plateVBX/MOsee page 17 VBX 25 M...: Protection with push-in seal IP 54; with cable glands IP 65Rated voltage 400 V With 4 captive lid screws4 fixing holes for screws Ø 5 mm inside the box (spacing: 45 mm)Nominal cross-section 2.5–4 mm
2 7 entries M20 Clear internal dimensions: 78 x 78 x 30.5Supplied with VBX 25 M: Supplied with VBX 25 M empty: 3 cable entries EDVS 203 cable entries EDVS 201 terminal strip VBX/KL 25 PP Polypropylene, light grey (RAL 7035) Please always state the ordering number when ordering.

15
