OBO
BETTERMANN
OBO V-TEC M cable glands
D1/D2
1
It}3
t
L2
halogen-free
G
Type
Colour
Pack
Weight
Ord. no.
qty
kg/100
PA
V-TEC M12X1.5
silver-grey
50
0.360
2022 25 7
V-TEC M16X1.5
silver-grey
50
0.630
2022 26 5
V-TEC M20x 1.5
silver-grey
50
1.000
2022 27 3
V-TEC M25X 1.5
silver-grey
25
2.350
2022 28 1
V-TEC M32X1.5
silver-grey
20
3.900
2022 30 3
V-TEC M40X1.5
silver-grey
10
7.500
2022 31 1
V-TEC M50X1.5
silver-grey
5
9.200
2022 45 1
V-TEC M63X1.5
silver-grey
5
9.660
2022 47 8
E
Nom. size
Sealing
Strain rel.
Hexagon
L
L1
L2
L3
L4
G
range D1 mm
and twist protection
D2
mm
SS
E
min.
ca
max. ca
mm
mm
mm
mm
M12X1.5
2.5- 6.5
3 - 6.5
15
16.5
18
23
8
5
12.6
7
M16X1.5
2.5- 8
3.5- 8
19
21
21
27
8
5
15.5
9
M20X1.5
5 -12
6 -12
24
27
23
30
9
5
18
10.5
M20X1.5NL
7 -14
7 -14
27
30
25
33
7
6
19
11
M25X1.5
9 18
12 -18
33
37.5
28
38
11
6
22
12.5
M32X1.5
14 -25
17 -25
42
47.5
32
43
11
7
24.5
14
M40X1.5
18 -32
20 -32
53
60
39
54
13
8
31
18
M50X1.5
24 -38
26 -38
60
68
42
57
13
9
32.5
19
M63X1.5
30 -44
30 -44
65
74
42
58
14
9
33
19.5
Type
Colour
Pack
Weight
Ord. no.
qty
kg/100
PA
V-TEC M12 X 1.5
1. grey
50
0.360
2022 33 8
V-TEC M16X1.5
1. grey
50
0.630
2022 34 6
V-TEC M20 X 1.5
1. grey
50
1.000
2022 35 4
V-TEC M20X1.5 NL
1. grey
50
1.380
2024 88 0
V-TEC M25X 1.5
1. grey
25
2.350
2022 36 2
V-TEC M32 X 1.5
1. grey
20
3.900
2022 37 0
V-TEC M40 X 1.5
1. grey
10
7.500
2022 39 7
V-TEC M50 X 1.5
1. grey
5
9.200
2022 48 6
V-TEC M63X1.5
1. grey
5
9.660
2022 49 4
Table column D1: Sealing range to VDE 0619, where no strain relief is required
Table column D2: Sealing range including strain relief and twist protection to VDE 0619
Type
Colour
Pack
Weight
Ord. no.
qty
kg/100
PA
V-TEC M12 X 1.5
black
50
0.360
202218 4
V-TEC M16X1.5
black
50
0.630
202219 2
V-TEC M20 X 1.5
black
50
1.000
2022 20 6
V-TEC M25X 1.5
black
25
2.350
2022 21 4
V-TEC M32X1.5
black
20
3.900
2022 22 2
V-TEC M40 X 1.5
black
10
7.500
2022 23 0
V-TEC M50 X 1.5
black
5
9.200
2022 43 5
V-TEC M63X1.5
black
5
9.660
2022 44 3
V-TEC M: With metric connecting thread to IEC 423
Cap-nut cable gland with wide sealing range, as well as strain relief and twist
protection for high sealing demands
Gasket of chloroprene/nitrile rubber
Moulded sealing, so no connecting industrial seal needed.
VDE tested, protection IP 68 at 5 bar
PA Polyamide, silver-grey (RAL 7001), light grey (RAL 7035), black Flame-retardant to VDE 0471/IEC 695 Part 2-1 Test temperature 750°C
CM
o o
CM CM
o
CM
>!
m
C5
CO
m
>
41
Please always state the ordering number when ordering.
