OBO

BETTERMANN

OBO V-TEC L cable glands


	V-TEC L	Pg 7	silver-grey		50	0.410	202417 9
	V-TEC L	Pg 9	silver-grey		50	0.670	202418 7
	V-TEC L	Pg 11	silver-grey		50	0.930	202419 5
	V-TEC L	Pg 13.5	silver-grey		50	1.090	2024 20 9
	V-TEC L	Pg 16	silver-grey		25	1.490	2024 21 7
	V-TEC L	Pg 21	silver-grey		25	2.330	2024 22 5
	V-TEC L	Pg 29	silver-grey		20	3.860	2024 23 3
	V-TEC L	Pg 36	silver-grey		10	7.750	2024 24 1
	V-TEC L	Pg 42	silver-grey		5	10.070	2024 26 8
	V-TEC L	Pg 48	silver-grey		5	10.730	2024 27 6
	With long connecting thread
	Type	Thread	Colour	Pack		Weight	Ord. no.
				qty		kg/100	PA

	V-TEC L	Pg 7	1. grey	50		0.410	2024 28 4
	V-TEC L	Pg 9	1. grey	50		0.670	2024 29 2
	V-TEC L	Pg 11	1. grey	50		0.930	2024 30 6
	V-TEC L	Pg 13.5	1. grey	50		1.090	2024 31 4
	V-TEC L	Pg 16	1. grey	25		1.490	2024 32 2
	V-TEC L	Pg 21	1. grey	25		2.330	2024 33 0
	V-TEC L	Pg 29	1. grey	20		3.860	2024 34 9
	V-TEC L	Pg 36	1. grey	10		7.750	2024 35 7
	V-TEC L	Pg 42	1. grey	5		10.070	2024 36 5
	V-TEC L	Pg 48	1. grey	5		10.730	2024 37 3
	With long connecting thread
	Type	Thread	Colour	Pack		Weight	Ord. no.
				qty		kg/100	PA

	V-TEC L	Pg 7	black	50		0.410	2024 38 1
	V-TEC L	Pg 9	black	50		0.670	2024 40 3
	V-TEC L	Pg 11	black	50		0.930	2024 41 1
	V-TEC L	Pg 13.5	black	50		1.090	2024 43 8
	V-TEC L	Pg 16	black	25		1.490	2024 44 6
	V-TEC L	Pg 21	black	25		2.330	2024 45 4
	V-TEC L	Pg 29	black	20		3.860	2024 46 2
	V-TEC L	Pg 36	black	10		7.750	2024 47 0
	V-TEC L	Pg 42	black	5		10.070	2024 48 9
	V-TEC L	Pg 48	black	5		10.730	2024 49 7


	Nom.	Sealing	Strain rel.	Hexagon			L	L1	L2	L3	L4
	size	range	and twist	SS	E	min.	max.	mm	mm	mm	mm
	G	D1 mm	prot. D2 mm			ca	ca
	Pg 7	2.5- 6.5	3 - 6.5	15	16.5	18	23	15	5	12.6	7
	Pg 9	2.5- 8	3.5- 8	19	21	21	27	15	5	15.5	9
	Pg 11	3.5-10	4.5-10	22	25	22	29	15	5	17	10
	Pg 13.5	5 -12	6 -12	24	27	23	30	15	5	18	10.5
	Pg 16	7 -14	7 -14	27	30	25	33	15	6	19	11
	Pg 21	9 -18	12 -18	33	37.5	28	38	15	6	22	12.5
	Pg 29	14 -25	17 -25	42	47.5	32	43	15	7	24.5	14
	Pg 36	18 -32	20 -32	53	60	39	54	18	8	31	18
	Pg 42	24 -38	26 -38	60	68.5	42	57	18	9	32.5	19
	Pg 48	30 -44	30 -44	65	74	42	58	18	9	33	19.5

Table column D1: Sealing range to VDE 0619, where no strain relief is required

Table column D2: Sealing range including strain relief and twist protection to VDE 0619

V-TEC L: With long Pg connecting thread to DIN 40430

Cap-nut cable gland with wide sealing range, as well as strain relief and twist

protection for high sealing demands

Gasket of chloroprene/nitrile rubber

Moulded sealing, so no connecting industrial seal needed.

VDE tested, protection IP 68 at 5 bar

With long connecting thread

PA Polyamide, silver-grey (RAL 7001), light grey (RAL 7035), black Flame-retardant to VDE 0471/IEC 695 Part 2-1 Test temperature 750°C

o o Ol Ol o

>!

m

C5

co m >

Please always state the ordering number when ordering. 39
