OBO

BETTERMANN

OBO V-TEC EX cable glands

halogen-free


Type	Thread	Colour	Pack	Weight	Ord. no.
			qty	kg/100	PA

V-TEC EX	Pg 7	black	50	0.410	2050 00 5
V-TEC EX	Pg 9	black	50	0.630	2050 01 3
V-TEC EX	Pg 11	black	50	0.890	2050 02 1
V-TEC EX	Pg 13.5	black	50	1.020	2050 04 8
V-TEC EX	Pg 16	black	25	1.380	2050 05 6
V-TEC EX	Pg 21	black	25	2.290	2050 06 4
V-TEC EX	Pg 29	black	20	4.020	2050 07 2
V-TEC EX	Pg 36	black	10	6.030	2050 08 0
V-TEC EX	Pg 42	black	5	7.650	2050 09 9
V-TEC EX	Pg 48	black	5	9.460	205010 2


Nom.	can be used for	Hexagon			L	L1	L2	L3	L4
size	cable diameter of	SS	E	min.	max.	mm	mm	mm	mm
G	mm			ca	ca
Pg 7	3.5- 6.5	15	16.5	18	23	8	5	12.6	7
Pg 9	5- 8	19	21	21	27	8	5	15.5	9
Pg 11	4.5-10	22	25	22	29	8	5	17	10
Pg 13.5	6.5-12	24	27	23	30	9	5	18	10.5
Pg 16	7 -14	27	30	25	33	10	6	19	11
Pg 21	12 -18	33	37.5	28	38	11	6	22	12.5
Pg 29	17 -25	42	47.5	32	43	11	7	24.5	14
Pg 36		53	60	39	54	13	8	31	18
Pg 42	24 -38	60	68.5	42	57	13	9	32.5	19
Pg 48	30 -44	65	74	42	58	14	9	33	19.5

Table column D1: Sealing range to VDE 0619, where no strain relief is required

Table column D2: Sealing range including strain relief and twist protection to VDE 0619

V-TEC EX: cable gland with EC design type approval certificate for products and protection systems for use in accordance with the regulations in explosion-hazard area - Directive 94/9/EC EC design type approval certificate number: PTB 99 ATEX 3112X and ... 3113X

With Pg connecting thread to DIN 40430

Cap-nut cable gland with wide sealing range, as well as strain relief and twist protection for high sealing demands

Gasket of chloroprene/nitrile rubber, moulded sealing, so no connecting industrial seal needed.

Tested to VDE 0619, protection IP 68 at 5 bar

PA Polyamide, black

Flame-retardant to VDE 0471/IEC 695 Part 2-1 Test temperature 750°C

o o >

■J)

38 Please always state the ordering number when ordering.
