OBO

BETTERMANN

OBO V-TEC cable glands

D1/D2


	Type	Thread	Colour	Pack	Weight	Ord. no.
				qty	kg/100	PA

	V-TEC	Pg 7	silver-grey	50	0.410	2022 60 5
	V-TEC	Pg 9	silver-grey	50	0.630	2022 61 3
	V-TEC	Pg 11	silver-grey	50	0.890	2022 62 1
	V-TEC	Pg 13.5	silver-grey	50	1.020	2022 64 8
	V-TEC	Pg 16	silver-grey	25	1.380	2022 65 6
	V-TEC	Pg 21	silver-grey	25	2.290	2022 66 4
	V-TEC	Pg 29	silver-grey	20	4.020	2022 67 2
	V-TEC	Pg 36	silver-grey	10	6.030	2022 68 0
	V-TEC	Pg 42	silver-grey	5	7.650	2022 69 9
	V-TEC	Pg 48	silver-grey	5	9.460	2022 70 2


	Nom.	Sealing	Strain rel.	Hexagon			L	L1	L2	L3	L4
	size	range	and twist	SS	E	min.	max.	mm	mm	mm	mm
	G	D1 mm	prot. D2 mm			ca	ca
	Pg 7	2.5- 6.5	3 - 6.5	15	16.5	18	23	8	5	12.6	7
	Pg 9	2.5- 8	3.5- 8	19	21	21	27	8	5	15.5	9
	Pg 11	3.5-10	4.5-10	22	25	22	29	8	5	17	10
	Pg 13.5	5 -12	6 -12	24	27	23	30	9	5	18	10.5
	Pg 16	7 -14	7 -14	27	30	25	33	10	6	19	11
	Pg 21	9 -18	12 -18	33	37.5	28	38	11	6	22	12.5
	Pg 29	14 -25	17 -25	42	47.5	32	43	11	7	24.5	14
	Pg 36	18 -32	20 -32	53	60	39	54	13	8	31	18
	Pg 42	24 -38	26 -38	60	68.5	42	57	13	9	32.5	19
	Pg 48	30 -44	30 -44	65	74	42	58	14	9	33	19.5


	Type	Thread	Colour	Pack	Weight	Ord. no.
				qty	kg/100	PA

	V-TEC	Pg 7	1. grey	50	0.410	2024 70 5
	V-TEC	Pg 9	1. grey	50	0.630	2024 71 3
	V-TEC	Pg 11	1. grey	50	0.890	2024 72 1
	V-TEC	Pg 13.5	1. grey	50	1.020	2024 74 8
	V-TEC	Pg 16	1. grey	25	1.380	2024 75 6
	V-TEC	Pg 21	1. grey	25	2.290	2024 76 4
	V-TEC	Pg 29	1. grey	20	4.020	2024 77 2
	V-TEC	Pg 36	1. grey	10	6.030	2024 78 0
	V-TEC	Pg 42	1. grey	5	7.650	2024 79 9
	V-TEC	Pg 48	1. grey	5	9.460	2024 80 2

Table column D1: Sealing range to VDE 0619, where no strain relief is required

Table column D2: Sealing range including strain relief and twist protection to VDE 0619


	Type	Thread	Colour	Pack	Weight	Ord. no.
				qty	kg/100	PA

	V-TEC	Pg 7	black	50	0.410	2024 51 9
	V-TEC	Pg 9	black	50	0.630	2024 53 5
	V-TEC	Pg 11	black	50	0.890	2024 54 3
	V-TEC	Pg 13.5	black	50	1.020	2024 55 1
	V-TEC	Pg 16	black	25	1.380	2024 57 8
	V-TEC	Pg 21	black	25	2.290	2024 58 6
	V-TEC	Pg 29	black	20	4.020	2024 59 4
	V-TEC	Pg 36	black	10	6.030	2024 60 8
	V-TEC	Pg 42	black	5	7.650	2024 61 6
	V-TEC	Pg 48	black	5	9.460	2024 62 4

V-TEC: With Pg connecting thread to DIN 40430

Cap-nut cable gland with wide sealing range, as well as strain relief and twist

protection for high sealing demands

Gasket of chloroprene/nitrile rubber

Moulded sealing, so no connecting industrial seal needed

Tested to VDE 0619

Protection IP 68 at 5 bar

PA Polyamide, silver-grey (RAL 7001), light grey (RAL 7035), black Flame-retardant to VDE 0471/IEC 695 Part 2-1 Test temperature 750°C

CM

o o

CM CM

o

C\J

>!

m

C5

CO m >

Please always state the ordering number when ordering. 37
