47
50 halogen-free chlorinefluorinebromine Type Colour Cartonqty Packqty Weightkg/100 Ord. no. PP 4040
4040 55
55 17.50013.000
17.00013.000 20018022001810
20018292001837 110 B9/T...: Comprises 2 halogen-free plastics components, 8 threaded entries(Pg 16) with push-through membrane (for cable diameter up to 15 mm)
including one in base. Where
cable glands are used (giving additional strainrelief) there is no need to remove the membrane (this saves time).Protection IP 67 with push-through membraneProtection IP 67 with cable gland without removal of the push-through membrane
Rated voltage 400 V; nominal cross-section 4-6 mm
2 The lid is secured with 4 pre-fitted rapid fixings (180 ° ).The fixing holes are additionally moulded with a soft plastics component forscrew ø 5 mm (spacing 75 mm). Clear internal dimensions: 98 x 98 x 40 Accessories available: Terminal stripsVBX/KL 60see page 29
Mounting plateVBX/MOsee page 17 B9/T with VBX/KL 60 2 fixing screw caps, 1 terminal strip VBX/KL 60 and 1 fixing screw plug B9/T empty and B9/T RED 2 fixing screw caps and 1 fixing screw plug B9/T NL 2 fixing screw caps, 1 fixing screw plug and 3 cable glands V-TEC/PA Pg 16 PP Polypropylene, light grey (RAL 7035) 47
M
50 halogen-free chlorinefluorinebromine Type Colour Cartonqty Packqty Weightkg/100 Ord. no. PP 4040
4040 55
55 17.50013.000
17.00013.000 20018452001853
20018612001888 110 B9/T M...: Comprises 2 halogen-free plastics components, 8 threaded en-tries (M20 x 1.5) with push-through membrane (for cable diameter up to 15
mm) including one in base.Where cable glands are used (giving additional strain relief) there is no needto remove the membrane (this saves time).Protection IP 67 with push-through membraneProtection IP 67 with cable gland without removal of the push-through membraneRated voltage 400 V; nominal cross-section 4-6 mm Accessories available:
2 Terminal stripsVBX/KL 60see page 29Mounting plateVBX/MOsee page 17 The lid is secured with 4 pre-fitted rapid fixings (180 ° ).The fixing holes are additionally moulded with a soft plastics component for
screw ø 5 mm (spacing 75 mm).Clear internal dimensions: 98 x 98 x 40 B9/T M with VBX/KL 60 2 fixing screw caps, 1 terminal strip VBX/KL 60 and 1 fixing screw plug B9/T M empty and B9/T RED 2 fixing screw caps and 1 fixing screw plug B9/T M NL 2 fixing screw caps, 1 fixing screw plug and 3 cable glands V-TEC/PA
M20 x 1.5 PP Polypropylene, light grey (RAL 7035)
14
Please always state the ordering number when ordering.
