Terminal strips
10 10 3.2
29.5max. 26 12 Type Packqty Weightkg/100 Ord. no. MF ø10.75 72.6 1 3.650 2016109 KL 60: Terminals of brass, nickel-platedScrews of steel, electro-galvanised and yellow-chromated
Nominal cross-section 4/6 mm Suitable for:
2 Damp-proof junction boxesB 40 Msee page 20B 60 Msee page 20 , rated voltage 660 VFive-pole, with clamp terminalsMax. connectable cross-sections per terminal: 3 x 6 mm
2 , 4 x 4 mm
2 ,5 x 2.5 mm
2 or 8 x 1.5 mm
2 MF Duroplast/melamine resin 150 (MF), light grey (RAL 7035),difficult to ignite
14.3 8.4 39.2 16 4.1 9
Type Packqty Weightkg/100 Ord. no. MF
33.5 17 1 7.000 2016125 7.5 87 Suitable for: KL 100: Terminals of brass, nickel-platedScrews of steel, electro-galvanised and yellow-chromated
Nominal cross-section 10 mm Damp-proof junction boxesB 100 Msee page 21B 11/L Msee page 24
2 , rated voltage 660 VFive-pole, with clamp terminalsMax. connectable cross-sections per terminal: 3 x 10 mm
2 , 4 x 6 mm
2 or 4 x 4 mm
2 MF Duroplast/melamine resin 150 (MF), light grey (RAL 7035),difficult to ignite
20.2max. 9 ø4.7
Type Packqty Weightkg/100 Ord. no. 11.7 MF 5.2
43.7ca 1 2.260 2017326 Suitable for: Damp-proof junction boxesA 9see page 18B 9 B Msee page 22B 10 Msee page 24 700/4 BM: Terminals of brass, nickel-platedScrews of steel, electro-galvanised and yellow-chromated
Nominal cross-section 2.5 mm
2 , rated voltage 660 VFive-pole, with socket terminalsMax. connectable cross-sections per terminal: 4 x 2.5 mm
2 , 5 x 1.5 mm
2 or 6 x 1 mm
2 MF Duroplast/melamine resin 150 (MF), light grey (RAL 7035),difficult to ignite
30
Please always state the ordering number when ordering.
