Nipples

ø23
8 Type Colour Packqty Weightkg/100 Ord. no. PE 100 0.100 2012030 89: Seal with push-through membrane for cable diameter 7–13 mm Requi-red hole diameter 18.5-19 mmWall thickness max. 1.8, suitable for junction box A 9 Suitable for: Damp-proof junction boxesA 9see page 18 PE Polyethylene, light grey (RAL 7035)Flame-retardant to VDE 0471/DIN IEC 695 Part 2-1Test temperature 750 ° C ø 23
8.6 Type Colour Packqty Weightkg/100 Ord. no. PE 100 0.100 2012049 Suitable for: 89/RK: Seal with push-through membrane for conduit diameter 12–16 mm.Required hole diameter 18.5-19 mm Wall thickness max. 3, suitable for junction box A 9 Damp-proof junction boxesA 9see page 18 PE Polyethylene, light grey (RAL 7035)

Terminal strips

2.4
28 8.7 Type Cartonqty Packqty Weightkg/100 Ord. no. PA 18
3.5 20 100 10 2.100 2009102 37.5 VBX/KL 25: Terminals and screws of steel,electro-galvanised and yellow-chromated Nominal cross-section 4 mm Suitable for:
2 , rated voltage 400 VFive-pole, with socket terminalsMax. connectable cross-sections per terminal: 3 x 4 mm OBO VARIOBOXVBX 25see page 15VBX 25 Msee page 15
2 , 4 x 2.5 mm
2 or 6 x 1.5 mm
2 PA Polyamide

28

Please always state the ordering number when ordering.
